- Page 1 HE408000TX Mission Hall Tree Bench For assistance with assembly, contact: Assembly Instruction Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#13112 250lb Max Seat Load Page 1...
- Page 2 HE408000TX Mission Hall Tree Bench Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity Of 2 Of 3 Of 8 Screw ∮5/32”x1” Adhesive Pad Dowel 5/16” x1-1/4” Quantity Quantity Quantity Of 2 Of 2 Of 2 Plastic Anchor Screw∮5/32”x1-1/2” Bolts∮ 1/4”x 1-1/4” Quantity Quantity Of 2 Of 2 Spring Washer Dia.1/4” Flat washer Dia.1/4”...
- Page 4 HE408000TX Mission Hall Tree Bench Assembly Instruction Attach Wooden Support Panel (C) to Back Panel (B) using Bolts (3) as shown. Tighten Bolts with Allen Wrench (6). Note: Make sure to insert the bolts all the way into the recessed...
- Page 5 Attach Seat Panel (D) to the bottom of Back Panel (B) using Bolts (4) and T-Nuts (5). Insert Bolts (3) through Seat Panel (D) and into Wooden Support Panels (C) as shown. Tighten bolts with Allen Wrench (6). Note: Bolts (4) have to be Figure 3 inserted into the T-Nuts threaded hole and...
- Page 6 Insert Cam Locks (2) into holes on the assembled unit from Figure 4. Screw Cam Bolts (1) into the threaded holes on the assembled unit from Figure 3. Attach the assembled unit from Figure 4 to the assembled unit from Figure 3 by inserting Cam Bolts (1) into corresponding holes until the assembled units meet.
- Page 7 Attach Hangers (7) to hall tree bench by using Screws (8) as shown. Tighten screw with Phillips screwdriver. Figure 7 Parts Replacement Form Page 7...
- Page 8 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
