Summary of Contents for Southern Enterprises Hendrik End Table Trunk
- Page 1 CK171200TX Hendrik End Table Trunk For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instructions Customer Service: 1-800-633-5096 service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Hendrik End Table Trunk Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 3 Quantity Quantity Quantity of 1 of 1 Front Knob-A Front Knob-B Hinges Quantity Quantity Quantity f 16 Screws Dia 1/8” x 1/2”L Side Knobs Bolts Dia 5/32” x 1/2”L Quantity Quantity of 2 of 8 Adhesive Pads Cotton Mats Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth.
- Page 4 Hendrik End Table Trunk Assembly Instructions Start screwing with fingers to help align Cam Bolts. Screw Cam Bolts (A) into holes on Front Panel (4) and Back Panel (5). Attach Front Panel (4) and Back Panel (5) to Bottom Panel (6) by inserting Cam Bolts (A) into corresponding holes.
- Page 5 Screw Cam Bolts (A) and insert Wood Dowels (C) into holes on Left Side Panel (2). Attach Left Side Panel (2) to assembled unit by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes. Insert Cam Locks (B) into holes on Bottom Panel (6), Front Panel (4) and Back Panel (5).
- Page 6 Tighten Bolts with Phillip screwdriver. Place Adhesive Pads (M) on top corners of Front Panel (4) as shown. Close Top (1) and let it drop down slowly. Figure 5 Now your Hendrik End Table Trunk is ready to use! Figure 6 Page | 6...
- Page 7 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
