- Page 1 HE408000TX Mission Hall Tree Bench For assistance with assembly contact: Assembly Instruction Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com 250lb Max Seat Load.
- Page 2 . Assembly Tool Required No.2 Phillips Screw Driver Tool List: 3/16" drill bit, drill, tape measure and pencil. HE408000TX Mission Hall Tree Bench Assembly Instruction...
- Page 3 PLEASE DO NOT OVERTIGHTEN CAMBOLTS. PLEASE STOP WHEN YOU FEEL TIGHT. Step 1: Attach wooden support panel (C) to back panel (B) by using bolt (3) as shown. Step 2: Attach top panel (A) to back panel (B) by using dowel (9), bolt (3) and screw (10).
- Page 4 Step 3: Attach seat panel (D) to back panel (B) by using bolt (4), washer (5) and bolt (3) as shown. Step 4: Attach front top stretcher (F), back top stretcher (G) and bottom stretcher (H) to side panel (E) by using cam bolt (1), cam lock (2) and dowel (12) as shown.
- Page 5 Step 6: Drill two 3/16" holes on the wall with measurements as shown. Please mount at least 1 screw into a wall stud. Insert plastic anchor (13) into the holes of wall as shown. (When doing this, you will need a hammer help you).
- Page 6 Extra hardware may be included. If any items are missing, please contact Southern Enterprises at 800-633-5096 or in Dallas (972) 869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues with your purchase. Please ask for a customer service representative for issues involving damages or replacement parts.
