Walton - Desk
Assembly Instructions -
Dimensions
Width - 121cm
Depth - 59.5cm
Height - 74cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
143/6886
MADE IN
BRITAIN
Issue 1 - 17/10/13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Walton 143/6886
Summary of Contents for Argos Walton 143/6886
- Page 1 Walton - Desk Assembly Instructions - 143/6886 Please keep for future reference Dimensions Width - 121cm Depth - 59.5cm MADE IN Height - 74cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 17/10/13...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 22kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D1429A) (1209 x 593mm) Left Side 3 Right Side (D1432A) (D1433A) (718 x 570mm) (718 x 570mm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the left side Tap 2 wooden dowels into the left side 10mm Note: Wooden dowels must not stick out from the edge by more than 10mm or they may Finished...
- Page 6 Assembly Instructions Step 3 Prepare the top rail Finished Insert 4 large locking front edge nuts into the top rail Gently tap the 2 mini blocks into the holes on the top rail orientated as shown. Step 4 Join the top rail and right side Push the top rail onto the right side...
- Page 7 Assembly Instructions Step 6 Fit the base rail Push the base rail onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the base rail Finished front edge Note: Support the base rail until the left side has been fitted in the next step.
- Page 8 Assembly Instructions Step 8 Prepare the top Screw 4 metal dowels Finished into the top front edge Step 9 Fit the top 2 people are needed here Finished front edge Lower the assembly onto the top Use a screwdriver to tighten the 4 large locking nuts fitted to...
- Page 9 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 12 ALR2916...
