Silicon Graphics SGI 1200 Quick Start Manual page 7

Figure 1 SGI 1200 Front View With Cover Removed
4. If you plan to use any options (for example, PCI boards, additional memory, and so
on), follow the instructions in the SGI 1200-Family of Servers User's Guide to install
these items.
Caution: Electrostatic discharge (ESD) can damage disk drives, add-in boards, and
other parts. This server can withstand normal levels of environmental ESD.
However, SGI recommends doing all procedures in this guide only at an
ESD-protected workstation. If one is not available, you can provide some ESD
protection by wearing an antistatic wrist strap attached to chassis ground of the
server—any unpainted metal surface—when handling components.
5. As applicable, follow the detailed procedures in Chapter 3 of the User's Guide to
install the unit into a rack.
6. Attach any of the following common peripherals that you intend to use at the
connectors shown in Figure 2:
• Keyboard: plug the keyboard into the keyboard port
• Mouse: plug the mouse into the mouse port
• Terminal: plug the display terminal into the video connector port on the rear of
the server and also into a power source, and turn the terminal on
Setting Up Your SGI 1200 Server
Blue AC power LED
Green disk activity LED
Green Ethernet activity LED
Amber global failure LED
3
