STANDALONE CONTROL CONNECTION
If connecting a bin slide to a standalone control, simply connect the circular connector from
the bin slide motor to a circular connector on the bottom of the box. The number of bin slides
usable per box will depend on the model ordered.
The standalone control will also need a power in from a power supply also using an M8 female
connector.
POWER IN
BIN SLIDE CONTROL OUT
Figure 7: Standalone Control
10
PTM007
