EasyWeld / HandyWeld 130
OUTPUT CURRENT
MIG
EasyWeld 130: W1201130
HandyWeld 130: W1200130
Version No: AA
Issue Date: 01-10-2021
STICK
PLATE THICKNESS
DIGITAL PRE-SETS
QUICK
SET
CONTROL
MIG
WARRANTY*
WARRANTY*
1
2
Manual No: 0-5618
Art # A-14846
OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIGWELD EasyWeld 130 and is the answer not in the manual?

Questions and answers

Related Manuals for ESAB CIGWELD EasyWeld 130

Summary of Contents for ESAB CIGWELD EasyWeld 130

  • Page 1 Art # A-14846 EasyWeld / HandyWeld 130 OPERATING MANUAL WARRANTY* OUTPUT CURRENT STICK WARRANTY* PLATE THICKNESS DIGITAL PRE-SETS QUICK CONTROL EasyWeld 130: W1201130 HandyWeld 130: W1200130 Version No: AA Issue Date: 01-10-2021 Manual No: 0-5618...
  • Page 2 YOU ARE IN GOOD COMPANY! The Brand of Choice for Contractors and Fabricators Worldwide. CIGWELD is a Market Leading Brand of Arc Welding Products for ESAB. We are a mainline supplier to major welding industry sectors in the Asia Pacific and emerging global markets including; Manufacturing, Construc- tion, Mining, Automotive, Engineering, Rural and DIY.
  • Page 3 CIGWELD EasyWeld / HandyWeld 130 Welding Inverters Instruction Manual Number 0-5618 for: Part Numbers W1201130 and W1200130 Published by: CIGWELD Pty Ltd CIGWELD An ESAB Brand 71 Gower Street, Preston, Victoria, Australia, 3072 +61 3 9474 7400 +61 3 9474 7391 www.cigweld.com.au...
  • Page 4 EasyWeld / HandyWeld 130 Be sure this information reaches the operator. You can get extra copies through your supplier. CAUTION These INSTRUCTIONS are for experienced operators. If you are not fully familiar with the principles of operation and safe practices for arc welding and cutting equipment, we urge you to read our booklet, “Safe Practices for Welding and Cutting,”...
  • Page 5 DECLARATION OF CONFORMITY According to AS/NZS 3820:2020, Essential Safety Requirements for Electrical Equipment Radiocommunications Labelling (Electromagnetic Compatibility) Notice 2017 Type of equipment Arc welding power source Type designation EasyWeld 130 with serial number from: GC131-xxxx-xxxx EasyWeld 160 with serial number from: GC132-xxxx-xxxx HandyWeld 130 with serial number from: GC133-xxxx-xxxx HandyWeld 160...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SECTION 1: ARC WELDING SAFETY INSTRUCTIONS AND WARNINGS ........1-1 1.01 Arc Welding Hazards ..................1-1 1.02 PRINCIPAL SAFETY STANDARDS ..............1-5 SECTION 2: INTRODUCTION ..................2-1 2.01 How To Use This Manual ................2-1 2.02 Equipment Identification ................. 2-1 2.03 Receipt Of Equipment ..................
  • Page 7 TABLE OF CONTENTS SECTION 6: ROUTINE SERVICE REQUIREMENTS AND POWER SOURCE PROBLEMS ....6-1 6.01 Routine Maintenance & Inspection ..............6-1 6.02 Cleaning the Welding Power Source ............... 6-1 6.03 Cleaning the Feed Rolls ................... 6-1 6.04 Basic Troubleshooting ..................6-1 6.05 Welding Power Source Problems ..............
  • Page 8 This Page Intentionally Blank...

  • Page 9: Arc Welding Safety Instructions And Warnings

    EasyWeld / HandyWeld 130 SECTION 1: ARC WELDING SAFETY INSTRUCTIONS AND WARNINGS WARNING PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY. PACE- MAKER WEARERS KEEP AWAY UNTIL CONSULTING YOUR DOCTOR. DO NOT LOSE THESE INSTRUCTIONS. READ OPERATING/INSTRUCTION MANUAL BEFORE INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT.
  • Page 10 EasyWeld / HandyWeld 130 2. Wear approved safety glasses. Side shields WARNING recommended. ARC RAYS can burn eyes and skin; NOISE can damage hearing. 3. Use protective screens or barriers to protect others from flash and glare; warn others not to Arc rays from the welding process produce in- watch the arc.
  • Page 11 EasyWeld / HandyWeld 130 4. Be alert that welding sparks and hot materials WARNING from welding can easily go through small cracks FUMES AND GASES can be hazardous to your and openings to adjacent areas. health. 5. Watch for fire, and keep a fire extinguisher Welding produces fumes and gases.
  • Page 12 EasyWeld / HandyWeld 130 6. Turn face away from valve outlet when opening The following is a quotation from the General cylinder valve. Conclusions Section of the U.S. Congress, Office of Technology Assessment, Biological Effects of 7. Keep protective cap in place over valve except Power when cylinder is in use or connected for use.

  • Page 13: Principal Safety Standards

    EasyWeld / HandyWeld 130 1.02 PRINCIPAL SAFETY STANDARDS Safety in welding and allied processes Part 1: Fire Precautions, AS 1674.1-1997 from SAI Global Limited, www.saiglobal.com. Safety in welding and allied processes Part 2: Electrical, AS 1674.2-2007 from SAI Global Limited, www. saiglobal.com.
  • Page 14 EasyWeld / HandyWeld 130 This Page Intentionally Blank GENERAL INFORMATION 0-5618...

  • Page 15: Introduction

    EasyWeld / HandyWeld 130 SECTION 2: INTRODUCTION 2.02 Equipment Identification 2.01 How To Use This Manual The unit’s identification number (specification or This Owners Manual only applies to the Part Numbers part number), model, and serial number are located listed on page i. on the Data Plate which is fixed to the bottom of the To ensure safe operation, read the entire manual, welding machine.

  • Page 16: Symbol Chart

    EasyWeld / HandyWeld 130 2.04 Symbol Chart Note that only some of these symbols will appear on your model. Wire Feed Function Single Phase Wire Feed Towards Workpiece With Three Phase Output Voltage Off. Three Phase Static Frequency Converter- Welding Gun Dangerous Voltage Transformer-Rectifier Increase/Decrease...

  • Page 17: Description

    EasyWeld / HandyWeld 130 2.05 Description 2.06 User Responsibility The Cigweld EasyWeld 130 and HandyWeld 130 This equipment will perform as per the information welding machines offer many benefits of a professional contained herein when installed, operated, maintained welding machine in a compact, portable, easy to use...

  • Page 18: Transporting Methods

    EasyWeld / HandyWeld 130 2.08 Transporting Methods These units are equipped with a handle for carrying purposes. WARNING ELECTRIC SHOCK can kill. DO NOT TOUCH live electrical parts. Disconnect input power conductors from de-energized sup- ply line before moving the welding power source. WARNING FALLING EQUIPMENT can cause serious personal injury and equipment damage.

  • Page 19: Specifications

    EasyWeld / HandyWeld 130 2.10 Specifications Description EasyWeld 130 HandyWeld 130 Packaged Part Number W1201130 W1200130 Power Source Part Number W1201131 W1200131 Power Source Dimensions (L) 357.5mm × (W) 148.6mm ×(H) 272.8mm Power Source Weight 7.6kg 7.2kg Cooling Fan Cooled Welder Type MIG Welding Inverter Power Source Australian Standard...
  • Page 20 EasyWeld / HandyWeld 130 NOTE 2 The Effective Input Current should be used for the determination of cable size & supply requirements. NOTE 3 Motor start fuses or thermal circuit breakers are recommended for this application. Check local requirements for your situation in this regard.

  • Page 21: Optional Accessories

    EasyWeld / HandyWeld 130 2.11 Optional Accessories We recommend genuine CIGWELD products. The biggest range and best quality with guaranteed performance. Part Number Description W6000600 Gas Nozzle OTW11/23/R Contact Tip 0.6mm OTW11/30/R Contact Tip 0.8mm OTW11/35/R Contact Tip 0.9mm OTW11/40/R Contact Tip 1.0mm OTW11/45/R Contact Tip 1.2mm W6000605 Gas Diffuser...
  • Page 22 EasyWeld / HandyWeld 130 Related Products Part Number Description 646766 WeldSkill Heavy Duty Welding Gloves - Medium 646755 WeldSkill Heavy Duty Welding Gloves - Large 646767 WeldSkill Heavy Duty Welding Gloves – XL 646771 WeldSkill Welding Jacket - Medium 646772 WeldSkill Welding Jacket - Large 646773 WeldSkill Welding Jacket - XL...

  • Page 23: Installation

    EasyWeld / HandyWeld 130 SECTION 3: INSTALLATION 3.04 Mains Supply Voltage 3.01 Environment Requirements These units are designed for use in environments with increased hazard of electric shock. The Mains Supply Voltage should be within ± 15% of the rated Mains Supply Voltage. If actual Mains A.

  • Page 24: Electromagnetic Compatibility

    EasyWeld / HandyWeld 130 7. The time of day that welding or other activities 3.07 Electromagnetic Compatibility are to be carried out. WARNING 8. The immunity of other equipment in the en- Extra precautions for Electromagnetic Compat- vironment: the user shall ensure that other ibility may be required when this Welding Power equipment being used in the environment Source is used in a domestic situation.
  • Page 25 EasyWeld / HandyWeld 130 4. Equipotential Bonding Bonding of all metallic components in the welding installation and adjacent to it should be considered. However. Metallic components bonded to the work piece will increase the risk that the operator could receive a shock by touching the metallic components and the electrode at the same time.
  • Page 26 EasyWeld / HandyWeld 130 This Page Intentionally Blank. INSTALLATION 0-5618...

  • Page 27: Operation

    EasyWeld / HandyWeld 130 SECTION 4: OPERATION 4.01 Overview Standard operating procedures apply when using these Welding machines, i.e. connect work lead directly to workpiece with the spring loaded clamp. The MIG wire is fed from the spool through the feed roller system and into the MIG Gun (consult CIGWELD or the electrode wire manufacturers information for the correct polarity).
  • Page 28 EasyWeld / HandyWeld 130 3. Over Temp Indicator This welding power source is protected by a self resetting thermostat. The Over Temp indicator will illuminate and the error E01 also will be displayed if the machine has over heated which normally occurs if the duty cycle of the power source has been exceeded.
  • Page 29 EasyWeld / HandyWeld 130 For example, if the Pre-set Voltage is 15V and in volts trim mode the setting is changed to -2.0 then the Pre-set voltage will now be 13V. If the Volts Trim is changed to 4.0 then the Pre-set Voltage will be 19V. 5.
  • Page 30 EasyWeld / HandyWeld 130 8. Negative Welding Output Terminal The negative welding terminal is used to connect the welding output of the power source to the work lead. Most General Purpose electrodes are connected with work lead to negative. Consult the electrode manufacturer’s information for the correct polarity.
  • Page 31 EasyWeld / HandyWeld 130 12. Shoulder strap (Not Shown) Shoulder Strap Assembly Instructions A black nylon shoulder strap is supplied with your welding machine. The strap is designed to be fitted into the sheet metal slot at the rear of the machine and through the plastic horizontal slot at the front panel housing. Strap details: Overall Length = 1.62m/1625mm, Width: 3.7cm/37mm, supplied with a Rubber Shoulder Comforter (L:150 x W:50mm) and two Plastic Buckles (W:45mm x L:31mm).
  • Page 32 EasyWeld / HandyWeld 130 This Page Intentionally Blank. OPERATION 0-5618...

  • Page 33: Mig (Gmaw) Welding

    EasyWeld / HandyWeld 130 SECTION 5: MIG (GMAW) WELDING 5.01 Shielding Gas Regulator/Flowmeter Operating Instructions WARNING This equipment is designed for use with welding grade (Inert) shielding gases only.. Shielding Gas Connection The CutSkill Preset Argon Regulator / Flowmeter and Gas Hose Kit is an optional accessory. Connect the gas regulator onto the gas cylinder/bottle by hand, keeping the round sight gauge in the vertical position.
  • Page 34 EasyWeld / HandyWeld 130 4. DO NOT use the regulator/flowmeter as a control valve. When downstream equipment is not in use for extended periods of time, shut off the gas at the cylinder valve and release the gas from the equipment. 5.
  • Page 35 EasyWeld / HandyWeld 130 2. Since the regulator is a preset type, no adjustments to the regulator are necessary. Before opening the cylinder valve, be sure that the flow adjusting valve is in a finger-tight "OFF" position (clockwise). 3. Slowly and carefully, open the cylinder valve until the maximum pressure registers on the high pressure gauge.

  • Page 36: Installing Minispool (100Mm Diameter)

    EasyWeld / HandyWeld 130 5.02 Installing Minispool (100mm diameter) As delivered from the factory, the unit is fitted with a Wire Spool Hub which accepts a Minispool of 100mm diameter. In order to fit a Minispool (100mm diameter) assemble parts in the sequence shown below in Figure 5-4. The nut and spring tighten the brake.

  • Page 37: Inserting Wire Into The Wire Feed Mechanism

    EasyWeld / HandyWeld 130 5.03 Inserting Wire into the Wire Feed Mechanism Release the tension from the pressure roller by turning the adjustable wire drive tension screw in an anti- clockwise direction. Then to release the pressure roller arm, lift the pressure roller arm tension screw upward to release the pressure roller arm (Figure 5-5).

  • Page 38: Feed Roll Pressure Adjustment

    EasyWeld / HandyWeld 130 5.04 Feed Roll Pressure Adjustment The pressure (top) roller applies pressure to the grooved feed roll via an adjustable pressure screw. These devices should be adjusted to a minimum pressure that will provide satisfactory WIREFEED without slippage. If slipping occurs, and inspection of the wire contact tip reveals no wear, distortion or burn back jam, the conduit liner should be checked for kinks and clogging by metal flakes and swarf.

  • Page 39: Wire Reel Brake

    EasyWeld / HandyWeld 130 A dual groove feed roll is fitted as standard. It can accommodate 0.8/0.9mm Gasless Flux Cored Wires. Markings are indicated on the side edge of the feed roll, for example 0.8, 0.9. GROOVE “A” GROOVE “B” GROOVE “A”...

  • Page 40: Setup For Mig (Fcaw) Welding With Gasless Mig Wire

    EasyWeld / HandyWeld 130 Wire Reel Brake Adjustment Nut Art # A-14865 Figure 5-10: Wire Reel Brake 5.07 Setup for MIG (FCAW) Welding with Gasless MIG Wire A. Ensure that the Power Source On/Off switch located on the rear of the Power Source is in the Off position. B.
  • Page 41 EasyWeld / HandyWeld 130 230/240 VAC Mains Supply MIG Gun Negative Welding Terminal (-) Positive Welding Terminal (+) Polarity Art # A-14851 Lead Work Lead Figure 5-11: Setup for MIG Welding with Gasless MIG Wire Select MIG Gasless Mode using the Process Selection Control button. (refer to section 4.02.1 for further information).
  • Page 42 EasyWeld / HandyWeld 130 Volts Trim NOTE! At this moment you can operate with the recommended welding Quick Set data , once an arc is established, the digital display will be changed to show the welding current. If the Welding Current is found to be too High or too Low for the application the Wire Feed Speed can be adjusted to the desired value.

  • Page 43: Setup For Mig (Gmaw) Welding With Gas Shielded Mig Wire

    EasyWeld / HandyWeld 130 5.08 Setup for MIG (GMAW) Welding with Gas Shielded MIG Wire Note: Argon Mini- Regulator and Gas Hose Kit Part No W4013010 is required in order to use Gas Shielded MIG Welding Wires. Note: Due to the higher Wire Feed Speed required to run ALU Wire successfully it must be run in the 0.6mm Wire Diameter, MIG Gas Mode.
  • Page 44 EasyWeld / HandyWeld 130 Gas Hose Preset Argon Regulator Preset Argon Regulator 230/240 VAC Shielding Gas Cylinder Mains Supply Shielding Gas Hose Supply Input Lead MIG Gun Negative Welding Terminal (-) Gas Inlet Connection Positive Welding Terminal (+) Polarity Art # A-14852 Lead Work Lead Figure 5-18: Setup for MIG Welding with Gas Shielded MIG Wire...
  • Page 45 EasyWeld / HandyWeld 130 Volts Trim NOTE! At this moment you can operate with the recommended welding Quick Set data , once an arc is established, the digital display will be changed to show the welding current. If the Welding Current is found to be too High or too Low for the application the Wire Feed Speed can be adjusted to the desired value.

  • Page 46: Mig (Gmaw/Fcaw) Basic Welding Technique

    EasyWeld / HandyWeld 130 5.09 MIG (GMAW/FCAW) Basic Welding Technique Two different welding processes are covered in this section (GMAW and FCAW), with the intention of providing the very basic concepts in using the MIG mode of welding, where a welding gun is hand held, the electrode (welding wire) is fed into a weld puddle, and the arc is shielded by an inert welding grade shielding gas or inert welding grade shielding gas mixture.
  • Page 47 EasyWeld / HandyWeld 130 The welding gun should be held at an angle to the weld joint. (see Secondary Adjustment Variables below) Hold the gun so that the welding seam is viewed at all times. Always wear the welding helmet with proper filter lenses and use the proper safety equipment.
  • Page 48 EasyWeld / HandyWeld 130 Distance from the MIG Gun Nozzle to the Work Piece The electrode wire stick out from the MIG Gun nozzle should be between 10mm to 20mm. This distance may vary depending on the type of joint that is being welded. Travel Speed The speed at which the molten pool travels influences the width of the weld and penetration of the welding run.
  • Page 49 EasyWeld / HandyWeld 130 3. Nozzle Angle. This refers to the position of the welding gun in relation to the joint. The transverse angle is usually one half the included angle between plates forming the joint. The longitudinal angle is the angle between the centre line of the welding gun and a line perpendicular to the axis of the weld.
  • Page 50 EasyWeld / HandyWeld 130 Setting of the Power Source Power source and Wirefeeder setting requires some practice by the operator, (however with the Quick Set feature of the EasyWeld/HandyWeld 130, setting up the correct parameters is a very simple procedure -refer to section 5.08), as the welding plant has two control settings that have to balance.

  • Page 51: Cigweld Mig Wire Selection Chart

    EasyWeld / HandyWeld 130 5.10 CIGWELD MIG Wire Selection Chart EasyWeld / HandyWeld 130 DESCRIPTION DIAMETER PACK PART NUMBER APPLICATION General purpose solid welding wire suitable for the all positional Gas Metal Arc Welding 0.6mm Minispool 0.9kg WS0906 WELDSKILL (GWAW) of mild and low alloy steels, used in SOLID general fabrication and for welding of light to WELDING...

  • Page 52: Mig (Gmaw/Fcaw) Welding Troubleshooting

    EasyWeld / HandyWeld 130 5.11 MIG (GMAW/FCAW) Welding Troubleshooting Solving Problems Beyond the Welding Terminals The general approach to fix Gas Metal Arc Welding (GMAW) problems is to start at the wire spool then work through to the MIG Gun. There are two main areas where problems occur with GMAW, Porosity and Inconsistent wire feed Solving Problems Beyond the Welding Terminals - Porosity When there is a gas problem the result is usually porosity within the weld metal.
  • Page 53 EasyWeld / HandyWeld 130 Solving Problems Beyond the Welding Terminals - Inconsistent Wire Feed Wire feeding problems can be reduced by checking the following points. FAULT CAUSE 1 Feed roll driven by motor in the A Wire spool brake is too tight. (Refer 5.08). wirefeed compartment slipping.
  • Page 54 EasyWeld / HandyWeld 130 Basic MIG (GMAW) Welding Troubleshooting FAULT CAUSE REMEDY 1 Undercut A Welding arc voltage too A Decrease voltage or increase the Wire Feed Speed. high. B Incorrect gun angle B Adjust angle. C Excessive heat input C Increase the gun travel speed and/or decrease welding current by decreasing the voltage or decreasing the Wire Feed Speed.

  • Page 55: Routine Service Requirements And Power Source Problems

    EasyWeld / HandyWeld 130 SECTION 6: ROUTINE SERVICE REQUIREMENTS AND POWER SOURCE PROBLEMS 6.02 Cleaning the Welding Power 6.01 Routine Maintenance & Source Inspection WARNING WARNING There are extremely dangerous voltage and There are extremely dangerous voltage and power levels present inside this product. Do power levels present inside this product.

  • Page 56: Welding Power Source Problems

    EasyWeld / HandyWeld 130 6.05 Welding Power Source Problems PROBLEM CAUSE REMEDY Mains Supply Voltage is A Power source is not in the A Set the power source to the On, the On/Off switch on correct mode of operation. correct MIG mode. Refer to the rear panel is in the On Section 4.02.1.
  • Page 57 EasyWeld / HandyWeld 130 PROBLEM CAUSE REMEDY Unit will not feed wire in A Incorrect Feed Roll fitted for A Fit the correct feed roll for MIG MIG mode. wire type being used. wire type being used. Refer to section 2.11 for optional feed rolls available and Section 5.05 for feed roll fitting details.
  • Page 58 EasyWeld / HandyWeld 130 PROBLEM CAUSE REMEDY Gas flow continues after Gas valve has jammed open Have an accredited CIGWELD the MIG Gun trigger switch due to impurities in the gas or service provider repair or has been released (MIG the gas line.

  • Page 59: Section 7: Key Spare Parts

    EasyWeld / HandyWeld 130 SECTION 7: KEY SPARE PARTS 7.01 Key Spare Parts Art # A-14847 Figure 7-1 Key Spare Parts (EasyWeld 130 shown as example) WELDSKILL EASYWELD 130 and HANDYWELD 130 POWER SOURCE KEY SPARE PARTS ITEM PART NUMBER DESCRIPTION W7007240 Control Knob...

  • Page 60: Mig Gun 3M Cmg13Dl Part No: W52Br13D3 Spare Parts

    EasyWeld / HandyWeld 130 7.02 MIG Gun 3m CMG13DL Part No: W52BR13D3 Spare Parts Art # A-14848 Figure 7-2 MIG GUN 3M CMG13DL PART NO: W52BR13D3 SPARE PARTS ITEM PART NUMBER DESCRIPTION W6000600 Gas Nozzle OTW11/23/R Contact Tip 0.6mm (Pack of 10) OTW11/30/R Contact Tip 0.8mm (Pack of 10) OTW11/35/R...

  • Page 61: Appendix 1: Circuit Diagram

    EasyWeld / HandyWeld 130 APPENDIX 1: CIRCUIT DIAGRAM 0-5618 APPENDIX...
  • Page 62 EasyWeld / HandyWeld 130 This Page Intentionally Blank. APPENDIX 0-5618...

  • Page 63: Cigweld - Limited Warranty Terms

    EasyWeld / HandyWeld 130 CIGWELD - LIMITED WARRANTY TERMS LIMITED WARRANTY: CIGWELD Pty Ltd, An ESAB Brand, hereafter, “CIGWELD” warrants to customers of its autho- rized distributors hereafter “Purchaser” that its products will be free of defects in workmanship or material. Should...
  • Page 64 EasyWeld / HandyWeld 130 WARRANTY SCHEDULE - EASYWELD 130 AND HANDYWELD 130 INVERTERS WARRANTY WARRANTY PERIOD – (Parts and Labour) EasyWeld 130 and HandyWeld 130 Inverter 1 Year Power Source ACCESSORIES WARRANTY PERIOD MIG Gun and Work Lead 3 Months MIG Gun consumable items CIGWELD Limited Warranty does not apply to;...
  • Page 65 EasyWeld / HandyWeld 130 This Page Intentionally Blank.
  • Page 66 CIGWELD Pty Ltd Malaysia - Indonesia - CIGWELD An ESAB Brand No 14 Jalan Teknologi 3/1 JI. Pulogadung No. 45 71 Gower Street, Preston VIC 3072 Australia Selangor Science Park 1 Kawasan Industri Pulogadung Customer Care: Kota Damansara, 47810 Petaling Jaya...
