Textron JACOBSEN R-311 69166 Technical/Repair Manual page 301

HYDRAULICS
1
6
1 Grease Fitting (2)
2 Barrel
3 Nut
4 Seal Ring
6-70
4
5
3
2
7
4
5
3
5 Piston
6 O-Ring (2)
7 Backup Washer
8 Spacer
Figure 6-76: Snap Ring Gland
6
7
12
11
14
13
16
15
15
TN1840
6
9 Rod
10 Lock Ring
11 Lock Ring
12 Wiper
9
8
10
8
11
10
14
12
13 Rod Seal
14 Rod Guide
15 O-Ring
16 O-Ring
4203781 First Edition
TN1840, TN1842
