OWNER/OPERATOR'S MANUAL
& ILLUSTRATED PARTS LIST
MODEL:
73-71010 ROUGH CUT MOWER RC466
WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
09-408 REV B
Advertisement
Table of Contents
Related Manuals for Textron JACOBSEN RC466
Summary of Contents for Textron JACOBSEN RC466
- Page 1 OWNER/OPERATOR’S MANUAL & ILLUSTRATED PARTS LIST MODEL: 73-71010 ROUGH CUT MOWER RC466 WARNING: If incorrectly used this machine can cause severe injury. Those who use and maintain this machine should be trained in its proper use, warned of its dangers and should read the entire manual before attempting to set up, operate, adjust or service the machine.
- Page 2 © 2003, TEXTRON INC...
-
Page 3: Table Of Contents
Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and instructions. You'll always be glad you did. Jacobsen, a Textron Company One Bob Cat Lane Johnson Creek, WI 53038-0469... -
Page 4: Description / Specifications
ROUGH DESCRIPTION / SPECIFICATIONS MOWER DESCRIPTION The RC466 Rough Cut Mower will cut through tall, dense growth and 1" woody stems. Free-swinging blades on discs all but eliminate shock load to the four spindles. Chains at the front opening allow unrestricted access for tall growth. -
Page 5: Safety
Your safety and the safety of others is involved. Jacobsen, a Textron Company strongly warns Signal word definitions against, rejects and disclaims any modifications, The signal words below are used to identify levels... - Page 6 ROUGH SAFETY MOWER GENERAL SAFETY • Never allow anyone to operate or service • Read and understand the owner’s manual, this machine while under the influence of before attempting to operate this machine. alcohol or drugs. • Operate all controls from the operator’s •...
- Page 7 ROUGH SAFETY MOWER SAFE OPERATION PRACTICES FOR 14. Use extra care when loading or unloading the machine into a trailer or truck. MOWERS 15. Always wear safety goggles or safety glasses with side shields when operating mower. This cutting machine is capable of amputating hands and feet and throwing objects.
- Page 8 ROUGH SAFETY MOWER DO NOT: IV SERVICE • Do not turn on slopes unless necessary, and 1. Use extra care in handling gasoline and other then, turn slowly and gradually downhill, if fuels. They are flammable and the vapors are possible.
-
Page 9: Decals
ROUGH DECALS MOWER Location: On mower deck right rear. Location: On mower deck top front center and both sides. Location: On drive belt shield. Location: On mower deck top left and right shields. Location: On mower drive line shield. -
Page 10: Installation
ROUGH INSTALLATION MOWER ATTACHING MOWER TO TRACTOR: Operate latch control to open hitch latches. Drive tractor into position aligning the quick hitch. Be sure both latches engage fully and and are placed in the locked position. Stop engine! Do not attempt to install drive belt with engine running. Release idler assembly to facilitate easy installation of the drive belt. - Page 11 ROUGH INSTALLATION MOWER REAR WEIGHT REQUIREMENTS The table of requirements for rear weights is based upon average mowing conditions and operator’s weight of 150 lbs. The recommendations may vary with the weight of the operator, other accessories, and the mowing conditions. It is the operator’s responsibility to determine the correct amount of weight needed to improve stability.
-
Page 12: Operation
ROUGH OPERATION MOWER OPERATING PRECAUTIONS Observe all Safety Decals. Keep all Shields in place. Do not operate mower with other persons in the area. Irregularities in ground surface can permit foreign material to be propelled from beneath deck to cause serious injury or death. Before leaving tractor, move Forward - Reverse control to neutral position, disengage PTO, set parking brake, lower mower deck and stop engine. -
Page 13: Service
ROUGH SERVICE MOWER MAINTENANCE Daily maintenance: Annual Maintenance: Visual inspection for loose parts and accumulation of grass and dirt. In addition to daily and 25 hour maintenance, remove the drive belts and check for cracks or wear. Rotate each Clean accumulation of grass clippings from beneath deck daily for better mowing spindle to check for roughness which would performance. - Page 14 ROUGH SERVICE MOWER ADJUSTMENTS Sharpening blades: Be careful while sharpening blades that the corners of the blade do not become rounded at the tips. This reduces the blades overlap and will cause skipping. Blades are reversible for extended wear. Simply flip over to use a new cutting edge. When installing new or sharpened blades be certain to replace right blades and left blades on the proper spindles.
- Page 15 ROUGH SERVICE MOWER 7. Replace the u-joint on the drive shaft and install 1. Raise deck to the highest cutting height and remove top shields. the drive shaft shield. 2. Remove drive shaft shield. Remove the front 8. Refer to the illustration and install the front spindle drive belt.
- Page 16 ROUGH MAIN FRAME MOWER FIGURE 1...
-
Page 17: Main Frame
ROUGH MAIN FRAME MOWER FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 6105106.7 MAIN FRAME 1-37 64163-06 WSHR-.768/.756X1.25X14 29-010 GREASE FITTING,1/4-28 1-38 55-Z9504AB BALL BRG-3/4 ID 90-1016 BOLT,5/8-11 X 2 (SN 1001 - 1224) 4132296 ROD END - 5/8 48043-04C CONE, OUTER BEARING 64163-16 WASHER-41/64 X 1-3/8 X 12... - Page 18 ROUGH PTO & DRIVE SHAFTS MOWER FIGURE 2...
-
Page 19: Pto & Drive Shafts
ROUGH PTO & DRIVE SHAFTS MOWER FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 6105087.7 DECK WLDMT 55-FB23012 BEARING 64123-50 BOLT-HEX 3/8-16X1 64141-4 NUT-WLF 3/8-16 6105082 SHAFT-SECONDARY 64164-02 KEY 3/16X3/16X1 SQ 83-BK40H PULLEY, 4" 83-H12 BUSHING 87-222 SHAFT-DRIVE PTO ASSY 2-10 6105106.7 MAIN FRAME 2-11... - Page 20 ROUGH SPINDLE ASSY & DRIVE BELTS MOWER FIGURE 3...
-
Page 21: Spindle Assy & Drive Belts
ROUGH SPINDLE ASSY & DRIVE BELTS MOWER FIGURE 3 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 83-BK65H PULLEY-6.5" 83-H18 BUSHING 64123-89 BOLT-HEX 1/4-20X3/4 83-012 PULLEY, IDLER 83-3BK65H SHEAVE D2902 SHEAVE 83-BK40H PULLEY-4" 83-034 IDLER 81-AA96 BELT-AA96 DOUBLE-V 81-A144 BELT-A144 HY-T 3-10 6105032 SPINDLE-FRONT... - Page 22 ROUGH DECK ASSY & SHIELDS MOWER FIGURE 4...
-
Page 23: Deck Assy & Shields
ROUGH DECK ASSY & SHIELDS MOWER FIGURE 4 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 6105087.7 MAIN DECK 4-41 64163-67 WASHER-.516X1X12 6105077.7 SKID SHOE-LFT 4-42 90-0826 BOLT,1/2-13 X 3-1/4 6105076.7 SKID SHOE-RT 4-43 64123-117 BOLT-HEX 1/2-13X1-1/2 6105062.7 RIGHT STRUT 4-44 64123-24 BLT-HEX 1/2-13X2... - Page 24 ROUGH DECALS MOWER FIGURE 5...
-
Page 25: Decals
ROUGH DECALS MOWER FIGURE 5 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 00-025 DECAL-KEEP HANDS 00-092 DECAL-HANDS & FEET 00-093 DECAL-RD OWNERS MAN 00-138 DECAL-ROTATING BLADES 2 4116761 DECAL-MADE IN THE USA 00-280 DECAL-KEEP GUARD IN PL 1 00-320 DECAL-KEEP HANDS LRG... - Page 26 Equipment from Jacobsen, a Textron company, is built to exacting standards ensured by ISO 9001 and ISO 14001 registration at all our manufacturing locations. A worldwide dealer network and factory-trained technicians backed by Textron Parts Xpress provide reliable, high-quality product support.
