Troubleshooting

8 Troubleshooting
Error
The sensor does not initial-
ize or react.
Door stops cyclically.
Door stops sporadically.
Test specimen is not
detected.
Table 8.1 Troubleshooting
9

Specifications / Wiring Diagram

General data
Sensing range min.
Sensing range max.
Light transmitter
Black/white differential (6 % / 90 %)
Approvals
Number of beams
Mode of operation
Diameter of the light spot
Displays/operating elements
LED
Operating components
Electrical data
Supply voltage
Current Consumption I
Input
Test input
Output
Output type
Signal output
Switching voltage
Switching current
Response time
Maximum length of the interconnecting
cables
Wire diameter
Optical data
Light wavelength
Laser class
Minimum reflection of the floor
Minimum reflection of the target
Cause
Supply voltage is not correct.
• The sensor is disturbed by the
movement of the door.
• The door panels are detected by
the sensor.
• The door movement causes vi-
brations.
• There are objects in the detection
field which move in the wind.
• The sensing range is incorrectly
set.
• The detection angle is incorrectly
set.
0 ... 1,500 mm ...
0 ... 2,500 mm ...
IRED
< 1 % at a sensing range of 2,000 mm
CE, TÜV
Number of mounted sensor modules (AIR 17-S)
Background evaluation
1,1 cm x 8,3 cm at a range of 2,000 mm for each module
LED red / green (see chapter "Optical Setting of the Sensor")
Sensing range adjustment
24 VDC ± 20 %
Master: < 75 mA
0
Slave: < 65 mA
-3 V ... +5 VDC or disconnected: Test off
+11 V...+30 VDC Test on
Relay switched off when objects are inside the sensing range.
1 Form C Relay
5 V ... 30 VAC / VDC
0.001 mA ... 0.3 A
70 ms
30 m
0.3 mm ... 1.3 mm (16AWG - 26AWG) Cu single/multicore
875 nm ± 15 nm
1
6 %
0 %
Remedy
Check the voltage supply.
• Change the sensor's detection
angle.
• Check the sensor's mounting.
• Remove the objects (flags, plants,
etc.)
• Check the sensing range with the
test card.
• Readjust the detection angle (see
Chapter 3.3).
23
