Mocka Sadie Entertainment Unit - Large Assembly Instructions Manual page 8

Sadie Entertainment Unit - Large
Assembly Instructions
13
F
F
F
C
8
C
C
5
Attach panel [2] to panel [4], [5], [8] and [9] using 8x dowels (C) and
secure with 8x screws (F), Tighten with a screwdriver.
