Sadie Entertainment Unit - Large
Assembly Instructions
7
B
5
B
6
Attach panels [5] and [7] to panel [23] secure with 4x locking nuts (B)
Attach panels [4] and [6] to panel [23] secure with 4x locking nuts (B)
Tighten with a screwdriver.
