MECHANICAL RELEASE

The Max SUPER ARM 1300 has a solid stainless steel output shaft and key lock for mechanical

release. For emergency release unlock the key and lift up the hood. To engage the actuator, push

down the hood and lock to resume automatic operation.

Front Bracket

Rear Bracket

The Max SUPER ARM 1300 ships with a heavy duty

half inch stock rear bracket that is broached and welded.

Both brackets front and rear, are silver zinc plated.
