5 Status LEDs and push buttons

LED
Run
Error
Port A (Tx/Rx) – KNX
Port B (Tx/Rx) – DALI #0
Button A – KNX
Button B – DALI #0
Push button
Button A – KNX
Button B – DALI #0
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
Colour
Off
Green
Off
Red
Off
Tx - Blinking green
Rx – Blinking yellow
Off
Tx - Blinking green
Rx – Blinking yellow
Off / Red
Off / Red
Functionality
Switches the IBOX between normal mode/programming mode
Sends to broadcast, alternatively: RECALL_MAX_LEVEL, OFF
User Manual r1.0 EN
Indication
No power
Device powered and working.
No error
Error
There is no activity on this port.
Every data packet sent to UFO device it
blinks
Every data packet received from UFO
device it blinks
There is no activity on this port.
Every data packet sent to UFO device it
blinks
Every data packet received from UFO
device it blinks
On if the IBOX is in programming mode
Indicates status of last command sent
from the button (On-
RECALL_MAX_LEVEL, Off-OFF)
After 30 secs of not pushing the button,
the LED turns OFF and next time the
button is pushed it will begin with
RECALL_MAX_LEVEL
