KNX – DALI
TM
Intesis
x x x Device Type
x x x Physical Minimum Level
x x x Min Level
x x x Max Level
x x x Power On Level
x x x System Failure Level
x x x Fade Time
x x x Fade Rate
x x x Arc Power Level
x x x Arc Power Off / On
x x x Step Down / Up
x x x Recall Min Level
x x x Recall Max Level
x x x Go to Scene
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
1 byte Unsigned Value 5.x
1 byte DPT_Scaling 5.001
1 byte DPT_Scaling 5.001
1 byte DPT_Scaling 5.001
1 byte DPT_Scaling 5.001
1 byte DPT_Scaling 5.001
1 byte Unsigned Value 5.x
1 byte Unsigned Value 5.x
1 byte DPT_Scaling 5.001
1 bit DPT_Switch 1.001
1 bit DPT_Step 1.007
1 bit DPT_Start 1.010
1 bit DPT_Start 1.010
1 byte Unsigned Value 5.x
0-Fluorescent
1-Emergency
2 Discharge
3-Halogen
T 4-Incandescent
R
5-Digital signal
6-LED
7-Switching
8-Colour Control
T 0 to 100 %
R
T
0 to 100 %
R
T 0 to 100 %
R
T
0 to 100 %
R
T 0 to 100 %
R
T
0 to 15
R
T 1 to 15
R
U Ri W
0 to 100 %
R
U Ri W 0-Off; 1-100 %
R
U Ri W 0-Step Down, 1-Step Up
R
U Ri W 1-Recall Min Level
R
U Ri W 1-Recall Max Level
R
U Ri W 0 to 15
R
