Summary of Contents for Modern Flames Sunset Charred Oak
- Page 1 Sunset Charred Oak SCO-26EL / SCO-20EL INSTALLATION/OWNERS MANUAL FOR USE IN UNITED STATES AND CANADA...
-
Page 2: Power Data
USER INSTRUCTIONS POWER DATA SCO-26EL SCO-20EL AC 120V/60Hz input AC 120V/60Hz input Transformer 12V DC output 12V DC output Lamps LED 12V LED 12V Rotor Motor 12V 15 r/min 12V 15 r/min 23” x 13” x 15” Shipping Size 30” x 16.5” x 15” 26lbs Shipping Weight 35lbs... -
Page 3: Installation
INSTALLATION INSTALLATION This log set is designed to fit into existing fireplaces as an insert to replace a wood or gas burning fire. This log set can also be used in cabinets or recessed wall openings. 1. Make sure the fireplace is clean and free of debris. -
Page 4: Operation
OPERATION OPERATION On the front face of the log set, near the bottom right side is the main power button. Push this button to begin using the fireplace. On the bottom of the log set are two push buttons that control the flame pattern and the brightness of the log set. Power button Touch Controls To begin operation press the Power button. - Page 5 OPERATION WIFI SETUP 1. Get started by downloading the Modern Flames app 4. Add a name for the from the Apple App home and the room Store or the Google which the fireplace is Play Store. New users located. Click done.
- Page 6 OPERATION 10. The fireplace will be 7. Enter your wi-fi added to your home. password and click Click on the logset to confirm. enter the command menu. 8. The app will connect the fireplace to your wi 11. From this screen you -fi network.
-
Page 7: Frequently Asked Questions
MAINTENANCE If you a re not going to be using wi-fi, it is recommended to disconnect the wi-fi board. Please follow the steps below. 1. Turn logset off and disconnect from power. 2. Turn logset around. 3. Locate wi-fi board on left side of the rear of the insert. 4. -
Page 8: Troubleshooting
MAINTENANCE TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION A. Replace batteries in remote A. Low Batteries control with - 2 AAA batteries B. Aim remote control to the right Can operate log set middle of the log set where the B. Not aiming control correctly functions with mechanical sensor is located controls but not remote... - Page 9 MAINTENANCE NOTES...
- Page 10 MAINTENANCE NOTES...
- Page 11 MAINTENANCE NOTES...
- Page 12 © 2018 www.modernflames.com Please dispose of properly.
