- Page 1 USER’S GUIDE SILICIUM ONE - WIFI...
-
Page 3: Table Of Contents
INDEX 1. INTRODUCTION ................. 4 2. INSTALLATION INSTRUCTIONS ............5 3. STARTING AND SETTING UP ..............6 3.1-SETTING UP THE WIFI CENTRAL UNIT ...................... 6 3.2 - HOW TO LINK HEATERS TO THE WIFI CENTRAL UNIT ..............7 3.3- SCREEN DISPLAY ............................. 7 3.4- SETTING UP THE HEATER .......................... -
Page 4: Introduction
1. INTRODUCTION Congratulations on your purchase of your SILICIUM ONE low consumption heater!! The product you have just purchased has undergone numerous tests and inspections to guarantee the highest quality. We hope it will give you entire satisfaction. Please, read carefully this user’s guide before installing your device. -
Page 5: Installation Instructions
2. INSTALLATION INSTRUCTIONS - The device includes a mounting kit with the required bolting: plugs and 6mm screws, and the wall support. - Plugs supplied with the mounting kit are not suitable for plaster walls. These walls require specific plugs. - Recommended clearances required... -
Page 6: Starting And Setting Up
It is necessary a Smartbox to control the heater using web or Smartphone apps. The Smartbox communicates the heater through the internet using the home router. 1- Register on the web app: avantwifi.climastar.es to connect via your computer or download the CLIMASTAR WIFI app from Google PlayStore or Apple AppStore and register. -
Page 7: How To Link Heaters To The Wifi Central Unit
3.2 - HOW TO LINK HEATERS TO THE WIFI CENTRAL UNIT Only if the heaters are linked to the WIFI central unit can they be controlled by the APPs. To link a heater, first enter the App, click “INSTALL” and follow the assistant: Once linked, an antenna with the Word “Link”... -
Page 8: Setting Up The Heater
3.4- SETTING UP THE HEATER First you have to set the level of maximum power that the heater will develop by connecting the appropriate switchs placed on the right lateral side of the heater. By selecting the round shape Switch in I position we will connect 500 W: ... - Page 9 One the heater power is decided, the user can set up the heater through the Web App (computer) or the mobile App in a very easy and intuitive way. In case there is no internet access, you can also set up the heater This can be done directly on the keyboard placed on the upper side of the device.
- Page 10 - Select the desired temperature by clicking +/-. Automatic mode - Select the automatic mode - Temperature settings: In the automatic mode, the set temperatures automatically change a per the user’s settings. The user assigns one of the 3 temperature options below per hour: ...
- Page 11 How to modify the selected temperature (e.g. comfort): Do not forget to confirm and validate: Prog - Time schedule modification Each radiator can be programmed hour per hour at any of the 3 available temperatures: comfort, eco and frost protection. E.g.
- Page 12 Day of the week Bar showing set temperature/time Time Temperature Start to programme Select the temperature at midnight, 00.00 Select the time Select the temperature and the following hour And so on until you have programmed each hour and each day of the week. Prog Do not forget to confirm and validate.
-
Page 13: Key Lock Function
Day of the week Minutes Hour Change the day of the week Change the time Change the minutes Exit - Temporary manual mode operation Being on the automatic mode, the user can increase or decrease the temperature; said modification will be set up until next change in programme. Modify manually the temperature in Auto mode. -
Page 14: Reset
“LOCK” word displays on the screen. Unlock 3.6- RESET - How to reset the heater Prog Do not forget to press “MOD” to confirm the reset - How to reset the smartbox - How to reset the USB smartbox... -
Page 15: Cleaning And Maintenance
4. CLEANING AND MAINTENANCE - Keep the room clean to avoid possible spots on the walls due to convection. - At the beginning of the year's heating season, vacuum any dust that has accumulated in the inner heating element while the radiator has been off for long periods during warmer weather. -
Page 16: Technical Specifications
5. TECHNICAL SPECIFICATIONS... -
Page 17: Faqs
6. FAQs PROBLEM PROBABLE CAUSE SOLUTION The heater does not The heater is in energy saving mode Increase the temperature in the heater if you need more room temperature. warm up Incorrect setting of the set temperature Check the set temperature on the display to verify it is the desired temperature. The room Improper sizing, the heater is too small for The power rating of the heater is not adequate for the place in which it has been... -
Page 18: Guarantee
7. GUARANTEE CLIMASTAR guarantees that in the moment of its purchase the product is free of any defect in the materials and in the work force (limited guarantee). CLIMASTAR offers a commercial and voluntary guarantee; conditions included are similar to those of the legal guarantee, being CLIMASTAR responsible for the non-conformities arisen in the terms and conditions mentioned below. - Page 20 CLIMASTAR GLOBAL COMPANY S.L. Carretera AS-266 OVIEDO-PORCEYO/ Km.7 Pruvia 33192 - Llanera (Asturias)- SPAIN Telf: 902 999 040 www.climastar.es ONE WIFI Rev. 270120...
