Figure 7. Installing an adapter in the cassette for the 9040-MR9 system
h) With the adapter retainers (D) in the open position, slide the retainers onto the strips.
i) Position the adapter retainers (D) so that they support the adapter and put them in the locked
position by rotating them in the direction that is shown.
Note: Ensure that the adapter is secured in the adapter retainer channel.
12 Power Systems: PCIe adapters for the 9040-MR9
