a) In the Linux session on the console, press Enter after you install or replace the adapter to put the
slot into the action state.
b) Enter the slot information with the lsslot command, as shown in the following example.
For example, if the slot in which you installed the PCIe adapter was U7879.001.DQD014E-P1-C3.
Enter lsslot -c pci -s U7879.001.DQD014E-P1-C3
The following screen is an example of the information that is displayed by this command:
# Slot
U7879.001.DQD014E-P1-C3 PCI-X capable, 64 bit, 133MHz slot 0001:40:01.0
12. Verify the installed part.
• If you replaced the part because of a service action, verify the installed part. For instructions, see
https://www.ibm.com/support/knowledgecenter/POWER9/p9ect/
pxect_verifyrepair.htm (www.ibm.com/support/knowledgecenter/POWER9/p9ect/
pxect_verifyrepair.htm).
• If you installed the part for any other reason, verify the installed part. For instructions, see https://
www.ibm.com/support/knowledgecenter/POWER9/p9haj/pxhaj_hsmverify.htm (www.ibm.com/
support/knowledgecenter/POWER9/p9haj/pxhaj_hsmverify.htm).
13. Turn off the identify LED. For instructions, see Deactivating an identify LED (www.ibm.com/support/
knowledgecenter/POWER9/p9haj/p9haj_turn_off_identify_led.htm).
Removing and replacing PCIe adapters in the 9040-MR9
Find information about removing and replacing a Peripheral Component Interconnect Express (PCIe)
adapter in the IBM Power System E950 (9040-MR9) server.
About this task
Note: Removing or replacing this feature is a customer task. You can complete this task yourself, or
contact a service provider to complete the task for you. You might be charged a fee by the service
provider for this service.
If your system is managed by the Hardware Management Console (HMC), use the HMC to repair a part in
the system. For instructions, see Repairing a part by using the HMC (www.ibm.com/support/
knowledgecenter/POWER9/p9haj/p9haj_hmc_repair.htm).
If your system is not managed by an HMC, complete the steps in the following procedures to remove and
replace a PCIe adapter in the system.
Preparing the 9040-MR9 system to remove and replace a PCIe adapter
To prepare the system to remove and replace a PCIe adapter in the system, complete the steps in this
procedure.
Before you begin
Note: If you are replacing a PCIe3 cable adapter that you use to attach your server to an EMX0 PCIe3
expansion drawer, you must ensure that you have the correct PCIe3 cable adapter and expansion drawer
cable to work with the PCIe3 6-slot fanout module that you have in your EMX0 PCIe3 expansion drawer.
• If you have a CCIN 50CB PCIe3 6-slot fanout module:
– You must use one of the following PCIe3 cable adapters:
- FC EJ08 (CCIN 2CE2)
- FC EJ07 (CCIN 6B52)
18 Power Systems: PCIe adapters for the 9040-MR9
