Barracuda CloudGen Firewall
F80 Revision A
https://campus.barracuda.com/doc/71862273/
Opening your Barracuda Networks appliance or removing its warranty label unless instructed to
do so by Barracuda Networks support will void your warranty and hardware support.
Barracuda Networks Appliance Safety Instructions
Always use the power supply shipped with the appliance. To prevent damage, connect the DC
plug to the appliance before plugging the power adapter into the AC outlet.
Default Port Configuration
Port Label OS Notation
1
p1
2
p2
F80 Revision A
Speed/Type
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
Management Port
X
1 / 6

Advertisement

loading

Related Manuals for Barracuda CloudGen F80

Summary of Contents for Barracuda CloudGen F80

  • Page 1 Barracuda CloudGen Firewall F80 Revision A https://campus.barracuda.com/doc/71862273/ Opening your Barracuda Networks appliance or removing its warranty label unless instructed to do so by Barracuda Networks support will void your warranty and hardware support. Barracuda Networks Appliance Safety Instructions Always use the power supply shipped with the appliance. To prevent damage, connect the DC plug to the appliance before plugging the power adapter into the AC outlet.

  • Page 2: Hardware Specifications

    Barracuda CloudGen Firewall 10/100/1000 MBit RJ45 10/100/1000 MBit RJ45 Hardware Specifications Interface RJ45 Ethernet NICs 4x 1 GbE USB 2.0 Serial console 1 [RJ45] Integrated Wi-Fi (IEEE 802.11b/g) Data Storage RAM [GB] 2 or higher Mass Storage Type • 30 (until 03/2017) Size [GB] •...

  • Page 3: Wall Mount Kit

    Your appliance is equipped with a variety of LEDs and acoustic signals. The front panel of the Barracuda CloudGen Firewall F80 A contains one power LED (blue), one disc LED (green), one status LED (red), and 4 port LEDs. On the back panel, you can see one power button LED and various port LEDs.
  • Page 4 Barracuda CloudGen Firewall LED Color Status Meaning Installation Meaning Operation Appliance is powered off or installation has not initialized All LEDs Off Off Appliance is powered off. far enough for LED control when installation is started. Power LED front side -...
  • Page 5 Barracuda CloudGen Firewall Parameter Value Baud 19200 Bits Stop bit Parity None Handshake None F80 Revision A 5 / 6...
  • Page 6 Barracuda Networks Inc. All specifications are subject to change without notice. Barracuda Networks Inc. assumes no responsibility for any inaccuracies in this document. Barracuda Networks Inc. reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
