5.1.2.2

Maximal hose package length

All information relates to the total hose package length of the complete welding system and presents
exemplary configurations (of components of the EWM product portfolio with standard lengths). A straight
kink-free installation is to be ensured, taking into account the max. delivery height.
Pump: Pmax = 3,5 bar (0.35 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
Pump: Pmax = 4.5 bar (0.45 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
16
Hose package Wire feeder
(20 m / 65 ft.)
(25 m / 82 ft.)
(15 m / 49 ft.)
Hose package Wire feeder
(30 m / 98 ft.)
(40 m / 131 ft.)
(40 m / 131 ft.)
miniDrive Welding torch
(25 m / 82 ft.) (5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
(10 m / 32 ft.) (5 m / 16 ft.)
miniDrive Welding torch
(25 m / 82 ft.) (5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
(25 m / 82 ft.) (5 m / 16 ft.)
Max.
30 m
98 ft.
Max.
30 m
98 ft.
40 m
131 ft.
45 m
147 ft.
70 m
229 ft.
