Design and function
Transport and installation
5.1.2

Welding torch cooling system

Insufficient frost protection in the welding torch coolant!
Depending on the ambient conditions, different liquids are used for cooling the welding
torch > see 5.1.2.1 chapter.
Coolants with frost protection (KF 37E or KF 23E) must be checked regularly to ensure that the
frost protection is adequate to prevent damage to the machine or the accessory components.
•
The coolant must be checked for adequate frost protection with the TYP 1 frost protection
tester .
•
Replace coolant as necessary if frost protection is inadequate!
Coolant mixtures!
Mixtures with other liquids or the use of unsuitable coolants result in material damage and
renders the manufacturer's warranty void!
•
Only use the coolant described in this manual (overview of coolants).
•
Do not mix different coolants.
•
When changing the coolant, the entire volume of liquid must be changed.
Dispose of the coolant in accordance with local regulations and the material safety data sheets.
5.1.2.1

Approved coolants overview

Coolant
KF 23E (Standard)
KF 37E
5.1.2.2

Maximal hose package length

All information relates to the total hose package length of the complete welding system and presents
exemplary configurations (of components of the EWM product portfolio with standard lengths). A straight
kink-free installation is to be ensured, taking into account the max. delivery height.
Pump: Pmax = 3,5 bar (0.35 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
Pump: Pmax = 4.5 bar (0.45 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
14
Temperature range
-10 °C to +40 °C
-20 °C to +30 °C
Hose package Wire feeder
(20 m / 65 ft.)
(25 m / 82 ft.)
(15 m / 49 ft.)
Hose package Wire feeder
(30 m / 98 ft.)
(40 m / 131 ft.)
(40 m / 131 ft.)
miniDrive Welding torch
(25 m / 82 ft.) (5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
(10 m / 32 ft.) (5 m / 16 ft.)
miniDrive Welding torch
(25 m / 82 ft.) (5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
(25 m / 82 ft.) (5 m / 16 ft.)
Max.
30 m
98 ft.
Max.
30 m
98 ft.
40 m
131 ft.
45 m
147 ft.
70 m
229 ft.
