Bradley Express EXD Series Installation Instructions Manual

For service only, deck lavatory system
Hide thumbs Also See for Express EXD Series:

Advertisement

Table of Contents

Read this entire installation manual to ensure proper installation, then file these
instructions with the owner or maintenance department.
Flush all the water supply lines before making connections. Debris in supply
lines will cause the valves to malfunction.
Turn OFF electrical power to the outlet when installing the Express® Deck.
Wall anchors used must have a minimum pull-out rating of 1,000 lbs.
Darker-colored solid surface materials require more maintenance and are
susceptible to "blushing" in applications where water temperature exceeds
110°F. For these applications we recommend mixing valve/tempered water
(mixing valves are available through your Bradley representative).
Product warranties may be found under "Product Information" on our web site at
www.bradleycorp.com.
215-1278 Rev. C; EN 03-817
© 2004 Bradley Corporation
Page 1 of 10
6/8/04
Installation
Instructions
For Service Only
EXD-3/WH97
Express® Deck Lavatory
System EXD Series
Express® Decks are ADA
compliant.

Table of Contents

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation Instructions . . . . . . . . . . . . . . . . . 3-8
Cleaning and Maintenance . . . . . . . . . . . . . . . . .8
Assembly of Components . . . . . . . . . . . . . . . . . .9
™
IMPORTANT
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: (262) 251-5817
http:\\www.bradleycorp.com
Valve . . . . . . . . . . . . . . . . . . . . . .10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Express EXD Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bradley Express EXD Series

Summary of Contents for Bradley Express EXD Series

  • Page 1: Table Of Contents

    “blushing” in applications where water temperature exceeds 110°F. For these applications we recommend mixing valve/tempered water (mixing valves are available through your Bradley representative). Product warranties may be found under "Product Information" on our web site at www.bradleycorp.com.

  • Page 2: Dimensions

    Express® Deck Lavatory System EXD Series EXD-3/WH97 Installation Instructions - For Service Only EXD-3/WH97 Express® Deck Dimensions (Standard Height Mounting) 6/8/04 Bradley Corporation • 215-1278 Rev. C; EN 03-817...

  • Page 3: Installation Instructions

    4. INFRARED FAUCET OPTION ONLY: Install the 110 volt GFCI electrical outlet per local code at the location shown in Figure 1a below or 1b on page 4. Standard Height Mounting - EXD-3/WH97 Figure 1a Bradley Corporation • 215-1278 Rev. C; EN 03-817 6/8/04...
  • Page 4 Express® Deck Lavatory System EXD Series EXD-3/WH97 Installation Instructions - For Service Only Juvenile Height Mounting - EXD-3/WH97 Figure 1b Figure 2 6/8/04 Bradley Corporation • 215-1278 Rev. C; EN 03-817...
  • Page 5 3/8" bolts and washers to mount the frame to the wall (see Figure 3 below and Figure 4 on page 6). FRAME (10) 3/8" BOLTS AND WASHERS (9) TORX-HEAD SCREW PANEL Figure 3 Bradley Corporation • 215-1278 Rev. C; EN 03-817 6/8/04...
  • Page 6 4. Tighten the screws installed in procedure #2 above to secure the bowl assembly to the frame. Do not overtighten. Figure 4 6/8/04 Bradley Corporation • 215-1278 Rev. C; EN 03-817...
  • Page 7 INSTALLER HOT SUPPLY STOP/STRAINER CHECK VALVE 7-5/8" (S60-003) (194mm) THERMOSTATIC MIXING VALVE (S01-116) Figure 5a Figure 5b #8 SCREW PLUG BOWL DRAIN PLUG RUBBER WASHER WASTE TEE WASTE SHOE Figure 6 Bradley Corporation • 215-1278 Rev. C; EN 03-817 6/8/04...

  • Page 8: Cleaning And Maintenance

    • Repair kit: In the unlikely event your Terreon® surface becomes damaged, it can easily and expensively be repaired. Contact your Bradley representative to order a repair kit and be sure to specify color when ordering.

  • Page 9: Assembly Of Components

    113-006DJ Vernatherm™ Thermostatic Mixing Valve Assembly TAILPIECE (129-007) NUT (110-005) COLD SUPPLY WASHER (124-001AF) 1/2"-14 NPT SUPPLIED BY INSTALLER HOT SUPPLY STOP/STRAINER CHECK VALVE 7-5/8" (S60-003) (194mm) THERMOSTATIC MIXING VALVE (S01-116) Bradley Corporation • 215-1278 Rev. C; EN 03-817 6/8/04...

  • Page 10: Vernatherm ™ Valve

    No Water Cold Valve shuts off or drips Correct Correct Cold Cold Cold Reversed Cold Cold/below 107° Hot/above 107° Reversed No Water Reversed No Water Cold Cold Reversed Reversed Cold Cold Cold 6/8/04 Bradley Corporation • 215-1278 Rev. C; EN 03-817...
