Installation
MG-3/AST4
Express® Lavatory
System - MG Series
with Pushbutton
Air Valve
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . . . 2
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Supplies Required . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Rough-Ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–8
Components . . . . . . . . . . . . . . . . . . . . . . . . . .9–10
Cleaning and Maintenance . . . . . . . . . . . . .11–12
Check Valve Troubleshooting . . . . . . . . . . . . . . .12
Metering Air Valve Troubleshooting . . . . . . . . . .13
Thermostatic Mixing Valve Troubleshooting . . . .14
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY
www.bradleycorp.com
Fax: 262-253-4161
