Bradley Express EXD Series Installation Instructions Manual

Lavatory system (standard and juvenile height)
Hide thumbs Also See for Express EXD Series:

Advertisement

Quick Links

Download this manual
Read this entire installation manual to ensure proper installation, then file these
instructions with the owner or maintenance department.
Flush all the water supply lines before making connections. Debris in supply
lines will cause the valves to malfunction.
Turn OFF electrical power to the outlet when installing the Express® Deck.
Wall anchors used must have a minimum pull-out rating of 1,000 lbs.
Product warranties may be found under "Product Information" on our web site at
www.bradleycorp.com.
215-1276 Rev. C; EN 03-817
© 2004 Bradley Corporation
Page 1 of 11
6/8/04
Installation
Instructions
For Service Only
EXD-3/STD
EXD-3/JUV
Express® Deck Lavatory
System EXD Series
(Standard and Juvenile
Height)
Table of Contents
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Installation Instructions . . . . . . . . . . . . . . . . . 4-9
Cleaning and Maintenance . . . . . . . . . . . . . . . .9
Assembly of Components . . . . . . . . . . . . . . . .10
Vernatherm™ Valve . . . . . . . . . . . . . . . . . . . . .11
IMPORTANT
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: (262) 251-5817
http://www.bradleycorp.com
