A Specifications

Physical Characteristics

Dimension
PCI Length x Width

Power Requirements

Specification
PCI operating voltage
PCI power consumption
Environmental Specifications
Condition
Temperature
Relative humidity
Altitude
Shock
Vibration, peak to
peak displacement
Vibration, peak
acceleration
34
Measurement
17.27 cm x 10.67 cm (6.8" x 4.2")
Measurement
+5 V ± 5%
14 Watts
2.8A @ +5VDC
Operating Specification
0˚C to 55˚C (+32˚F to +131˚F)
5% to 85% (non-condensing)
40˚C, 16 hour dwells at extremes
Up to 3,048 meters (10,000 ft.)
10g, 1/2 sine wave, 11 msec
0.0127 cm. (0.005 in.) max
(5 to 32 Hz)
0.25g (5 to 500 Hz)
(Sweep Rate = 1 octave/min.)
Storage Specification
–40˚C to +85˚C
(–40˚F to +185˚F)
5% to 95%
(non-condensing)
10˚C/hour
Up to 10670 meters
(35,000 ft.)
60g, 1/2 sine wave,
11 msec
0.2540 cm. (0.1 in.) max
(5 to 17 Hz)
0.25g (5 to 500 Hz)
(Sweep Rate =
1 octave/min.)
