4. FEATUREs AND PREPARATION PROCEDURE OF M3LDY

The M3LDY is a field configurable signal transmitter using a simulator and an indicator, without a PC or a dedicated setting

unit.

For instance, select an input type and range with the DIP switches on the unit to set input. Then apply a desired minimum

or maximum input from the simulator and press a front button to memorize the value as minimum or maximum value. Easy

and reasonable M-System's one-step calibration (hereafter called 'One-Step Cal') realizes automatic I/O ranging and cali-

bration only by pressing a button once.

Before using the unit, perform the calibration according the following flow. The procedure depends on the configuration

options or modes.

• Two configuration modes are available with the model M3LDY-R/A, field configuration using the DIP SW / control

buttons (hereafter called 'DIP SW configuration') and the PC configuration.

• The model M3LDY-R/B is for the DIP SW configuration only.

DIP SW con guration

INPUT RANGING

• With front control buttons and a simulator.

OUTPUT RANGING

• With front control buttons, a simulator

and a multimeter.

CONFIGURING DIP SW

WIRING & MOUNTING ON DIN RAIL

POWER ON

STARTING OPERATION

M3LDY OPERATING MANUAL EM-2664-B Rev.0

PC con guration

I/O SETTING AND CALIBRATION

• Using the PC Con gurator Software

(model: M3LDYCON).
