■ I/O RANGING MODE & FINE ADJUsTMENT MODE
The LED status in the I/O ranging and fine adjustments using the 'One-Step Cal' is shown in the following tables.
MODE
LED
Input ranging
Output ranging
NOTE
In the I/O ranging and fine adjustments using the PC Configurator Software (model: M3LDYCON), the LEDs are not ac-
cording to the above tables.
MODE
LED
Fine zero adjustment
Fine span adjustment
M3LDY OPERATING MANUAL EM-2664-B Rev.0
