Terminal Assignment - M-system M3-UNIT Series Operating Manual

Current loop supply (linearizing; field- and pc-configurable)

Hide thumbs Also See for M3-UNIT Series:

Table of Contents

■ WIRING TO TERMINAL BLOCK

Insert a wire into the dead end of a terminal block and fix it with a minus screwdriver with the blade edge 0.6 mm (0.02")

and the blade width 3.5 mm (0.14") (torque: 0.5 – 0.6 N∙m).

8.3 TERMINAL AssIGNMENT

Power

Output signal

Input signal

M3LDY OPERATING MANUAL EM-2664-B Rev.0
