10.2.2 MAXIMUM RANGE AND MINIMUM sPAN OF INPUT

The maximum range and minimum span of the input are shown in the following tables.
10.2.2.1 DC current input
MAXIMUM RANGE
0 to 20 mA DC
NOTE
The ex-factory setting is 4 – 20 mA DC unless otherwise specified.

10.2.3 MAXIMUM RANGE, MINIMUM sPAN AND DEFAULT VALUE OF OUTPUT

The maximum range, minimum span and default value of the output are shown in the following tables. The default value
means initial 0% and 100% output when the DIP switch setting is changed.
10.2.3.1 DC current output
MAXIMUM RANGE
0 to 20 mA DC
10.2.3.2 DC voltage output (narrow spans)
MAXIMUM RANGE
-2.5 to +2.5 V DC
10.2.3.3 DC voltage output (wide spans)
MAXIMUM RANGE
-10 to +10 V DC
NOTE
The ex-factory setting is 4 – 20 mA DC unless otherwise specified.
MINIMUM SPAN
2 mA
MINIMUM SPAN
1 mA
MINIMUM SPAN
250 mV
MINIMUM SPAN
1 V
DEFAULT VALUE
4 to 20 mA DC
DEFAULT VALUE
-1 to +1 V DC
DEFAULT VALUE
1 to 5 V DC
M3LDY OPERATING MANUAL EM-2664-B Rev.0 27
