Internal View - M-system M3-UNIT Series Operating Manual

Current loop supply (linearizing; field- and pc-configurable)
Hide thumbs Also See for M3-UNIT Series:
Table of Contents

Advertisement

5.2 INTERNAL VIEW

(1) SW1
Sets output type.
(2) SW2
Sets input type, output type, front control button lock and configuration mode.
(3) SW3
Sets input type.
(1) SW1
(2) SW2
(3) SW3
M3LDY OPERATING MANUAL EM-2664-B Rev.0
13
