Configuration - continued
Press the +-button to go on to
the next page.
5. Configuration of Analog
outputs
Press the +-button to go on to
the next page
6. Configuration of Analog
Input signals
76
Function
Voltage signal for high pressure
valve, ICMTS
Stepper signal for by-pass valve, CCM
Speed control, compressor
Speed control, gas cooler fan
Speed control, pump - tw
Speed control, pump - hr
Sensor
Disch. gas temperature - Sd
Suction gas temperature - Ss
Outdoor temp. - Sc3
Thermostat sensor in plant room -
Saux1
Suction pressure - Po
Condenser pressure - Pc
Refrigerant receiver, Prec-CO2
Oil receiver, Prec-Oil
Tap water temperature - Stw2
Tap water temperature - Stw3
Tap water temperature - Stw4
Tap water temperature - Stw8
Heat reclaim temperature Shr2
Heat reclaim temperature Shr3
Heat reclaim temperature Shr4
Heat reclaim temperature Shr8
Temp. gas cooler outlet Sgc
Temp. by-pased gas Shp
Gas cooler pressure Pgc
Capacity controller RS8GG602 © Danfoss 2015-03
Output
Module
Point
Type
AO1
1
24
Step 1
3
9
AO1
5
5
AO2
5
6
AO3
5
7
AO4
5
8
Input
Module
Point
Type
AI1
1
1
Pt 1000
AI2
1
2
Pt 1000
AI3
1
3
Pt 1000
AI5
1
5
Pt 1000
AI6
1
6
AKS 2050-59
AI7
1
7
AKS 2050-159
AI7
2
7
AKS 2050-159
AI8
2
8
AKS 2050-159
AI1
3
1
Pt 1000
AI2
3
2
Pt 1000
AI3
3
3
Pt 1000
AI4
3
4
Pt 1000
AI5
3
5
Pt 1000
AI6
3
6
Pt 1000
AI7
3
7
Pt 1000
AI8
3
8
Pt 1000
AI1
5
1
Pt 1000
AI2
5
2
Pt 1000
AI4
5
4
AKS 2050-159
5 - Analog outputs
The possible signals are
the following:
0 -10 V
2 – 10 V
0 -5 V
1 – 5V
Stepper output
Stepper output 2
0-10 V
Stepper user defined: See
CCM
section "Miscellaneous"
0 - 10 V
0 - 10 V
6 - Analog inputs
The possible signals are
0 - 10 V
the following:
0 - 10 V
Temperature sensors:
• Pt1000
• PTC 1000
Pressure transmitters:
• AKS 32, -1 – 6 bar
• AKS 32R, -1 – 6 bar
• AKS 32, - 1 – 9 bar
• AKS 32R, -1 – 9 bar
• AKS 32, - 1 – 12 bar
• AKS 32R, -1 – 12 bar
• AKS 32, - 1 – 20 bar
• AKS 32R, -1 – 20 bar
• AKS 32, - 1 – 34 bar
• AKS 32R, -1 – 34 bar
• AKS 32, - 1 – 50 bar
• AKS 32R, -1 – 50 bar
• AKS 2050, -1 – 59 bar
• AKS 2050, -1 – 99 bar
• AKS 2050, -1 – 159 bar
• User defined (only
ratiometric, min. and max
value of the pressure
range must be set)
S4 Cold brine
Pctrl
Po suction pres.
Ss suction gas
Sd disch. temp.
Pc Cond. Pres.
S7 Warm brine
Sc3 air on
Ext. Ref. Signal
• 0 – 5 V,
• 0 -10 V
Olie receiver
HP control
Pgc
Prec
Sgc
Shp
Stw2,3,4,8
Shr2,3,4,8
HC 1-5
Heat recovery
Saux 1 - 4
Paux 1 - 3
Voltage input 1 - 5
• 0 -5 V,
• 0 -10 V,
• 1 – 5 V,
• 2 – 10 V
PI-in temp
PI-ref temp
PI- in voltage
PI-in pres.
PI-ref pres.
AK-PC 781
