Configuration - continued
AK-PC 781 Capacity controller RS8GG602 © Danfoss 2015-03
Pgc HR offset: Pressure displacement at max. voltage
signal
HP low limit: Signal in % at which "Pgc HR min." comes
into force.
HP high limit: Signal in % at which "Pgc HR offset" value
is used.
FAN CONTROL
Fan - Max Cond. Ref offset: Set the displacement at which
the fans shall fully stop.
Fan low limit: Signal in % at which throttling of the fans
commences
Fan high limit: Signal in % at which the fans are stopped
BYPASS CONTROL
V3gc bypass stop limit: Signal in % at which the gas
cooler connects again after completed disconnect.
V3gc bypass start limit: Signal in % at which the gas
cooler is disconnected.
Flowswitch delay: Duration of stable signal before the
new status is used in the regulation.
