Danfoss ADAP-KOOL AK-PC 781 Design Manual page 15

Point
At the top the
signal input is
the left of the
two terminals.
At the bottom
the signal input
is the right of the
two terminals.
S
Pt 1000 ohm/0°C
P
AKS 32R
3: Brown
2: Blue
1: Black
AKS 32
3: Brown
2: Black
1: Red
U
On/Off
AK-PC 781
Signal Signal
type
S1
S2
Saux
Pt 1000
SsA
SdA
Shr
Stw
Sgc
P0A
AKS 32R /
P0B
AKS 2050
PcA
-1 - xx bar
PcB
Paux
AKS 32
Pgc
-1 - zz bar
Prec
0 - 5 V
...
0 - 10 V
Active at:
Ext.
Main
switch Closed
Day/ /
Night Open
Door
Level
switch
Capacity controller RS8GG602 © Danfoss 2015-03
Point 1 2 3 4
Type AI1 AI2 AI3 AI4
Point 5 6 7
Type AI5 AI6 AI7
Signal Module
9:
Terminal
10:
Terminal
15:
Terminal
16:
Terminal
Terminal
11, 12, 13, 14:
(Cable screen)
8
AI8
Point
Terminal
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5 (AI 5) 17 - 18
6 (AI 6) 19 - 20
7 (AI 7) 21 - 22
8 (AI 8) 23 - 24
12 V
5 V
5 V
12 V
Signal type /
Active at
15
