- Page 1 ™ ™ Horizon Ice Machine Models with RIDE Technology Installation Instructions for Drop-Ins HCD/HMD/HCF/HMF1000RJS, HCD/HMD/HCF/HMF1400RJS, HCD/HMD/HCF/HMF1650RJS, HCD/HMD1000NJS, HCD/HMD1400NJS, HCD/HMD1650NJS (See model number confi gurator on page 2 for details.) Order parts online www.follettice.com remote condensing Stock Module Identification Plate 208264 Module No.
- Page 2 Chewblet ® Ice Machine Model Number Configurations 1400 Icemaker Voltage Series Condenser Application Configuration MC Maestro™ C 208-230/60/1 (icemaking head) 400 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 454 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (206kg)
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Dispenser preparation Louvered docking assembly Ice transport tube External connection Internal connection Front cover DROP-IN • RIDE Technology remote condensing...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➊ ➋ ➌ ➍ 1/2" 1/2" ➎ ➏ DROP-IN • RIDE Technology remote condensing...
-
Page 5: Site Preparation
Potable water supply • 10-70 psi (69-483kpa) • 45-90 F (7-32 C) • Follett recommends the use of an in-line water fi ltration system (item# 00130286) ➌ Drain • The drain line from the ice machine must have at least 1/4" per foot pitch (6,4mm/0,3m) ➍... -
Page 6: Dispenser Preparation
Dispenser preparation Prepare the dispenser. Dispenser preparation Hot Water 160 F (71 C) ➒ 12" ➌ ➐ (304,8mm) min. ➋ ➊ ➍ ➎ ➏ 4" ➓ (101,6mm) ➐ ➑ • Determine best route for ice transport tube run. Note: 12" (304,8mm) clearance is required. ➊... - Page 7 Louvered docking assembly Install the louvered docking assembly. Wall bracket accessory Machine stand accessory • Mount louvered docking assembly to • Mount louvered docking assembly to wall machine stand accessory bracket accessory Louvered docking assembly 1-3/4" (44,5mm) 3" (76mm) ➋ 1"...
-
Page 8: Docking Station
Undercounter installation requirements Top View ➌ ➊ 1.75" (45mm) min. Access panel/ door on counter 24.5" min. (623mm) 21" min. (534mm No Lip ➋ DOCKING STATION • Position and screw louvered docking assembly to the bottom of counter inside of access panel/ ➊... -
Page 9: Ice Transport Tube
Ice transport tube Install the ice transport tube. Ice transport tube installation from dispenser to ice machine ➋ Hot Water 160 F (71 C) ➎ ➊ 1/4" ➌ ➍ ➏ ➐ Stock Module Identification Plate 208264 Module No. Product Service No. Ice transport tube tips ➊... -
Page 10: External Connections
External connections Connect utilities to louvered docking assembly. Water and drain Refrigerant ➊ ➋ ➊ • Braze supplied expandable refrigerant • Remove access panel if necessary. ➊ lines in place ➊ • Install drain line The rigid drain line from the ice machine must have at least 1/4"... -
Page 11: Internal Connections
Internal connections Connect louvered docking assembly to ice machine. Ice transport tube installation Water and drain lines ➊ ➋ ➋ ➊ ➋ ➊ • Slide ice machine into louvered docking ➊ • Insert potable water line into valve ➊ assembly •... - Page 12 Power cord • Position plate into opening and secure with supplied screw DROP-IN • RIDE Technology remote condensing...
-
Page 13: Front Cover
Front cover Install front cover to ice machine. Install condensing unit Install ice machine front cover ➋ ➊ • Slide ice machine cover over machine ensuring that tabs on back of cover • Complete installation of condensing unit slip under louvers on back of louvered ➊... - Page 14 Long tube run recommendations ➊ max. 2 ft (.6m) ➋ 1/4" ➊ • Pitch ice transport tube to allow melt water to drain towards ice machine ➋ • Secure insulated ice transport tube at least every 2 ft (.6m) to prevent dips or traps DROP-IN •...
- Page 15 DROP-IN • RIDE Technology remote condensing...
- Page 16 Horizon, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge, RIDE and Vision are trademarks of Follett Corporation. Chewblet is a registered trademark of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00159996R08 www.follettice.com...
