Ice Machine Models with RIDE Technology ™ ™ Installation Instructions for Ice Storage Bins HMD/HCD710ABS, HCC1010ABS, HMC1010ABS, HCC1410ABS, HMC1410ABS, HCC1010WBS, HMC1010WBS, HCC1410WBS, HMC1410WBS, HCE1010ABS, HME1010ABS, HCE1410ABS, HME1410ABS, HCE1010WBS, HME1010WBS, HCE1410WBS, HME1410WBS (See model number configurator on page 2 for details.) Order parts online www.follettice.com...
Page 2
Chewblet Ice Machine Model Number Configurations ® 1810 Application Configuration Icemaker Voltage Series Condenser MC Maestro™ C 208-230/60/1 (icemaking head) 425 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 425 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (193 kg)
Page 3
Read and complete the following 8 installation steps Unpack Site preparation Bin preparation Louvered docking assembly External connection Ice transport tube Internal connection Front cover BIN • RIDE Technology self-contained...
Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ BIN • RIDE Technology...
• 10-70 psi (69-483kpa) • 45 to 90 F (7 to 32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable...
Page 6
Bin preparation Prepare the bin Bin top preparation Bin top preparation • Remove protective tape from gaskets • Apply gaskets ➊ • Install shuttle actuator ➋ through dispenser top and secure with locking nut ➌ BIN • RIDE Technology self-contained...
Louvered docking assembly Install the louvered docking assembly. BEFORE PROCEEDING Prior to installing the louvered docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. An optional straight drain fitting is also supplied. You may need to remove the back panel of the docking assembly in order to re-orient or change the drain fitting.
Ice transport tube Install the ice transport tube. Ice transport tube installation ➍ ➏ ➐ ➋ Hot Water 160 F (71 C) ➎ ➑ ➒ ➊ ➓ 1/4˝ (6,4mm) ➌ 1' (0,3m) Ice transport tube tips ➊ • Insulate entire length of ice transport tube •...
Internal connections Connect louvered docking assembly to ice machine. CAUTION • Plug must be accessible after final installation. • H_E1410A/W 230/50/1 requires a 20A circuit (4.00 mm wire) Air-cooled ice machines – follow steps 7.1 through 7.5. Ice transport tube Potable water and drain lines ➋...
Water-cooled ice machines – follow steps 7.6 through 7.12. Cooling lines Set TDS switch HIGH CLEAN • Install ice machine cooling water lines to • Set the TDS switch on the electrical box: louvered docking assembly HIGH: for extended service life LOW: for low-scale water Ice transport tube Potable water and drain lines...
Page 12
7.10 Power cord Cooling lines and power ➋ ➊ • Remove twist tie • Carefully pass cord thru opening and plug • Connect cooling water lines to ice into wall outlet machine ➊ • For H_E units, install a suitable plug •...
Front cover Install front cover to ice machine. Install front cover Front cover installation – air-cooled undercounter only ➊ ➋ ➋ ➌ ➊ ➌ • Slide ice machine cover over machine ensuring that tabs on back of cover slip under louvers on back of louvered docking assembly ➊...
Page 14
Long tube run recommendations max. 2 ft (0,6m) ➊ ➋ 1/4" (6,4mm) 1' (0,3m) ➊ • Pitch ice transport tube to allow melt water to drain towards ice machine ➋ • Secure insulated ice transport tube at least every 2 ft (0,6m) to prevent dips or traps BIN •...
