HCD/HMD/HCF/HMF1000RBT, HCD/HMD/HCF/HMF1400RBT, HCD/HMD/HCF/HMF1650RBT,
HCD1000NBT, HMD1000NBT, HCD1400NBT, HMD1400NBT, HCD1650NBT, HMD1650NBT
(See model number confi gurator on page 2 for details.)
Order parts online
www.follettice.com
™
Horizon
Ice Machine Installation Instructions
for Ice Storage Bin Top-mount Applications
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
208264
Stock Module Identification Plate
Module No.
Product
Service No.
remote condensing
00159962R09
Advertisement
Table of Contents
Related Manuals for Follett Horizon Chewblet series
Summary of Contents for Follett Horizon Chewblet series
- Page 1 ™ Horizon Ice Machine Installation Instructions for Ice Storage Bin Top-mount Applications HCD/HMD/HCF/HMF1000RBT, HCD/HMD/HCF/HMF1400RBT, HCD/HMD/HCF/HMF1650RBT, HCD1000NBT, HMD1000NBT, HCD1400NBT, HMD1400NBT, HCD1650NBT, HMD1650NBT (See model number confi gurator on page 2 for details.) Order parts online www.follettice.com remote condensing 208264 Stock Module Identification Plate Module No.
- Page 2 ® Chewblet Ice Machine Model Number Configurations 1400 Icemaker Voltage Series Condenser Application Configuration MC Maestro™ C 208-230/60/1 (icemaking head) 400 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 454 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (206kg)
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Bin preparation Louvered docking assembly Ice transport tube External connection Internal connection Front cover BIN • TOP-MOUNT remote condensing...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➊ ➋ ➌ ➍ 1/2" 1/2" ➎ ➏ BIN • TOP-MOUNT remote condensing...
-
Page 5: Site Preparation
Potable water supply • 10-70 psi (69-483kpa) • 45-90 F (7-32 C) • Follett recommends the use of an in-line water fi ltration system (item# 00130286) ➌ Drain • The drain line from the ice machine must have at least 1/4" per foot pitch (6,4mm/.3m) ➍... - Page 6 Bin preparation Prepare the bin. Bin top preparation Bin top preparation ➋ ➊ ➌ ➊ ➊ • Remove protective tape from • Apply gaskets gaskets ➋ • Install shuttle actuator through bin top ➌ and secure with locking nut BIN • TOP-MOUNT remote condensing...
- Page 7 Louvered docking assembly Install the louvered docking assembly. Louvered docking assembly 1-3/4" (44,5mm) 3" (76mm) ➋ 1" (25,4mm) 3/8" ∅ Stub Typ high pressure line 3" (76mm) ➊ 1000, 1400: 5/8" ∅ low pressure line 1650: 7/8" ∅ low pressure line ➊...
-
Page 8: Refrigerant Lines
Refrigerant lines ➊ • Braze supplied expandable refrigerant ➊ lines in place BIN • TOP-MOUNT remote condensing... -
Page 9: Ice Transport Tube
Ice transport tube Install the ice transport tube. ➋ Hot Water 160 F (71 C) ➊ ➌ • Slide insulation onto ice transport tube • Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with ➊... -
Page 10: External Connections
External connections Connect utilities to louvered docking assembly. Water and drain ➋ ➊ • Remove access panel if necessary. ➊ • Install drain line The rigid drain line from the ice machine must have at least 1/4" per foot pitch (6,4mm/0,3m). -
Page 11: Internal Connections
Internal connections Connect louvered docking assembly to ice machine. Ice transport tube installation Water and drain lines ➊ ➋ ➋ ➊ ➋ ➊ • Slide ice machine into louvered docking ➊ • Insert potable water line into valve ➊ assembly •... - Page 12 Power cord • Position plate into opening and secure with supplied screw BIN • TOP-MOUNT remote condensing...
- Page 13 BIN • TOP-MOUNT remote condensing...
-
Page 14: Front Cover
Front cover Install front cover to ice machine. Install condensing unit Install ice machine front cover ➋ ➊ • Slide ice machine cover over machine ensuring that tabs on back of cover • Complete installation of condensing unit slip under louvers on back of louvered ➊... - Page 15 BIN • TOP-MOUNT remote condensing...
- Page 16 Horizon, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge, RIDE and Vision are trademarks of Follett Corporation. Chewblet is a registered trademark of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00159962R09 www.follettice.com...
