HCD/HMD/HCF/HMF1010RBT, HCD/HMD/HCF/HMF1410RBT,
HCD1010NBT, HMD1010NBT, HCD1410NBT, HMD1410NBT
(See model number configurator on page 2 for details.)
Order parts online
www.follettice.com
Horizon Elite
™
for Ice Storage Bin Top-mount Applications
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Ice Machine Installation Instructions
remote condensing
01113315R00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Horizon Elite
Summary of Contents for Follett Horizon Elite
- Page 1 Horizon Elite Ice Machine Installation Instructions ™ for Ice Storage Bin Top-mount Applications HCD/HMD/HCF/HMF1010RBT, HCD/HMD/HCF/HMF1410RBT, HCD1010NBT, HMD1010NBT, HCD1410NBT, HMD1410NBT (See model number configurator on page 2 for details.) Order parts online www.follettice.com remote condensing 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 •...
- Page 2 Chewblet Ice Machine Model Number Configurations ® 1400 Icemaker Voltage Series Condenser Application Configuration MC Maestro™ C 208-230/60/1 (icemaking head) 400 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 454 lbs Chewblet W Water-cooled, self-contained H Harmony™ (RIDE remote ®...
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Bin preparation Louvered docking assembly Ice transport tube External connection Internal connection Front cover BIN • TOP-MOUNT remote condensing...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➊ ➋ ➌ ➍ 7/16" 7/16" ➎ ➏ BIN • TOP-MOUNT remote condensing...
-
Page 5: Site Preparation
• 10-70 psi (69-483kpa) • 45-90 F (7-32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable federal, state, and local codes Drain ➌... - Page 6 Bin preparation Prepare the bin. Bin top preparation Bin top preparation — – ˜ – • Remove protective tape from ➊ • Apply gaskets gaskets ➋ • Install shuttle actuator through bin top and secure with locking nut ➌ BIN • TOP-MOUNT remote condensing...
- Page 7 Louvered docking assembly Install the louvered docking assembly. Louvered docking assembly 2" (50,8 mm) 1.88" (47,8 mm) ➋ ➊ 3/8˝ ∅ 1" (25,4 mm) high pressure Stub Typ line 3.38" (86 mm) ➊ 1010, 1410: 5/8" ∅ low pressure line •...
-
Page 8: Ice Transport Tube
Ice transport tube Install the ice transport tube. ➋ Hot Water 160 F (71 C) ➊ ➌ • Slide insulation onto ice transport tube • Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers ➊... -
Page 9: External Connections
External connections Connect utilities to louvered docking assembly. Water and drain Refrigerant lines ➋ ➊ ➌ ➊ • Remove access panel if necessary. • Braze supplied expandable refrigerant lines in place ➊ • Install drain line ➊ The rigid drain line from the ice machine must have at least 1/4"... -
Page 10: Internal Connections
Internal connections Connect louvered docking assembly to ice machine. Ice transport tube installation Water line ➋ ➊ ➋ ➊ • Slide ice machine into louvered docking ➊ • Insert potable water line into valve assembly ensuring that drain tube is fully ➊... - Page 11 Power cord TDS switch HIGH CLEAN • Position plate into opening and secure • Set the TDS switch on the electrical box: with supplied screw HIGH: for extended service life LOW: for low-scale water BIN • TOP-MOUNT remote condensing...
-
Page 12: Front Cover
Consult Operation and Service Manual provided with ice machine for sanitizing instructions. Horizon, Horizon Elite, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge and Vision are trademarks of Follett Corporation. Chewblet, RIDE and Follett are registered trademarks of Follett Corporation, registered in the US.
