Basic Installation Procedure

WVR5200 Installation and Safety Instructions
Your instrument is shipped in a fully enclosed metal chassis. You can operate the
instrument in the provided chassis or install the chassis in an approved portable
cabinet or rack adapter.
To install your instrument in a cabinet or rack, follow the instructions that are
included with the optional accessory kits that are available for each type of
installation. Also refer to the Environmental Ratings section for cooling and
clearance requirements. (See page 9, Environmental Ratings.)
CAUTION.
Do not install this instrument in any cabinet except those that are
listed in the Accessories table; attempting to do so can damage the instrument
and the cabinet.
If you need to install your instrument in a custom application, such as a console,
be sure to provide adequate airflow and make sure the intake air to the side vents
do not exceed 40 °C. Do not block or restrict the ventilating holes. Refer to the
Environmental Ratings section for cooling and clearance requirements. (See
page 9, Environmental Ratings.)
When installing in a custom application, use the Rack Adapter clearances.
CAUTION.
To prevent risk of fire, adequate airflow must be maintained. Failure
to provide adequate airflow to the instrument could cause the instrument to
shut down. Inadequate airflow includes placing the instrument in any small,
enclosed room that lacks a ventilation system, such as a closet. If the airflow is
restricted or blocked and the instrument does not shut down, the instrument could
be permanently damaged and increases the risk of fire.
Basic Installation Procedure
13
