Adjustment Procedures
Table 5-2: Adjustment steps (cont.)
Input Setup diagram
Ch 1 Sinewave
generator
Edge
5–6
2-ch model 4-ch model
step number step number
35 35
36 36
37 37
38 38
39 39
40 40
41 41
42 42
43 43
44 44
45 40
46 46
47 47
48 48
49 49
50 50
51 51
52 52
53 53
Signal Signal source setting
Sinewave Generator, 5 kHz, 1 V
50 Ω
Sinewave Generator, 1 MHz, 100 mV
50 Ω
1 MHz, 1 V
Sinewave Generator,
50 Ω
Sinewave Generator, 50 kHz, 1 V
50 Ω
Sinewave Generator, 20 MHz, 1 V
50 Ω
Sinewave Generator, BWL, 25 mV
50 Ω
Sinewave Generator, BWL, 50 mV
50 Ω
Sinewave Generator, BWL, 100 mV
50 Ω
Sinewave Generator, BWL, 250 mV
50 Ω
Sinewave Generator, BWL, 500 mV
50 Ω
BWL, 1 V
Sinewave Generator,
50 Ω
Sinewave Generator, 5 kHz, 2.5 V
50 Ω
Sinewave Generator, 1 MHz, 2.5 V
50 Ω
Sinewave Generator, 50 kHz, 2.5 V
50 Ω
Sinewave Generator, 20 MHz, 2.5 V
50 Ω
Sinewave Generator, BWL, 2.5 V
50 Ω
Sinewave Generator, BWL, 5 V
50 Ω
Sinewave Generator, BWL, 1.6 V
50 Ω
Edge, 50 Ω. 1 kHz, 0 to -800 mV
