3. Connect the oscilloscope channel under test to the DC voltage source as
shown in the following figure:
4. For each vertical scale (volts/division) setting in the following table, perform
the following steps:
a. Set the DC voltage source output level to the positive voltage listed and
then record the mean measurement as V
b. Reverse the polarity of the DC voltage source and record the mean
measurement as V
c. Calculate V = V
diff
the following table:
Vertical Scale
(volts/div) setting
5 mV/div
200 mV/div
2 V/div
5. Set DC voltage source output level to 0 V.
6. Disconnect the test setup.
7. Repeat steps 1 through 6 for all input channels.
.
pos
.
neg
- V and compare V
pos neg
DC voltage
source output levels
+17.5 mV, -17.5 mV
+700 mV, -700 mV
+7.00 V, -7.00 V
TDS2000C Series Oscilloscope Service Manual
to the accuracy limits in
diff
Accuracy limits for V
diff
33.6 mV to 36.4 mV
1.358 V to 1.442 V
13.58 V to 14.42 V
