Table 5-2: Adjustment Steps - Tektronix TDS2022C Technical Reference

Table 5-2: Adjustment steps

Input Setup diagram
Ch 1 DC voltage 1
through
Ch x
Ext Trig DC voltage 2
TDS2000C Series Oscilloscope Service Manual
2-ch model 4-ch model
step number step number
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
20 20
21 21
22 22
23 23
24 24
25 25
26 26
27 27
28 28
29 29
30 30
31 31
32 32
33 33
34 34
Signal Signal source setting
DC Voltage 1 0.0 V
-20.0 V
DC Voltage 1
DC Voltage 1 -2.0 V
DC Voltage 1 -1.6 V
DC Voltage 1 -1.2 V
DC Voltage 1 -0.8 V
DC Voltage 1 -0.4 V
DC Voltage 1 -0.32 V
DC Voltage 1 -0.2 V
DC Voltage 1 -0.16 V
DC Voltage 1 -0.08 V
DC Voltage 1 -0.04 V
-0.03 V
DC Voltage 1
DC Voltage 1 -0.02 V
DC Voltage 1 -0.015 V
DC Voltage 1 0.015 V
DC Voltage 1 0.02 V
0.03 V
DC Voltage 1
DC Voltage 1 0.04 V
DC Voltage 1 0.08 V
DC Voltage 1 0.16 V
DC Voltage 1 0.2 V
0.32 V
DC Voltage 1
0.4 V
DC Voltage 1
DC Voltage 1 0.8 V
DC Voltage 1 1.2 V
DC Voltage 1 1.6 V
DC Voltage 1 2.0 V
20.0 V
DC Voltage 1
DC Voltage 1 0.0 V
DC Voltage 2 -5.0 V
DC Voltage 2 -1.0 V
DC Voltage 2 1.0 V
5.0 V
DC Voltage 2
Adjustment Procedures
5–5
