Troubleshooting; Adjustment After Repair; Required Tools And Equipment; Troubleshooting Tree - Tektronix TDS2022C Technical Reference

Troubleshooting

Adjustment After Repair

Required Tools and
Equipment

Table 6-3: Tools and equipment

Tools and equipment
Oscilloscope with 1X/10X and 100X
probes
DMM
USB flash drive
USB type A to type B cable
PC with USB host post and
with TekVISA (OpenChoice PC
Communications) installed

Troubleshooting Tree

TDS2000C Series Oscilloscope Service Manual
This section contains information and procedures to help you isolate a defective
module in the oscilloscope.
WARNING.
Before performing this or any other procedure in this manual, read the
General Safety Summary and Service Safety Summary found at the beginning of
this manual. Also, to prevent possible injury or damage to electrical components,
read Preventing ESD. (See page 6-1, Preventing ESD.)
If you replace the Main board or power supply, you must adjust the oscilloscope
after repair. Refer to the chapter Adjustment Procedures.
Use the following tools and equipment to troubleshoot the oscilloscope:
Example
Tektronix TDS2000C series oscilloscope with standard accessory 10X probe (TPP0201 or
TPP0101) and optional 100X probe (P5100 or P5200)
3.5 or greater digit DMM
Tektronix part number 119-7276-00, 128 MB
Tektronix part numbers: 174-4401-00, 0.91 meters (3 feet) 174-5194-00, 1.83 meters (6 feet)
PC with USB communication port
To isolate a problem to a specific troubleshooting procedure, use the
troubleshooting tree that is shown on the next four pages. Detailed procedures
follow the tree.
