DVI over Single CAT5 Direct Plug-in
Extender
User Manual
1
4
7
-
1
4
7
rev: 131002
Made in Taiwan
The CV-147
DVI over Single CAT5 Direct Plug-in Extender
safety regulations and requirements, and has been certified for international use. However, like all
electronic equipments, the CV-147 should be used with care. Please read and follow the safety
instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION..................................................................................................................... 1
FEATURES ............................................................................................................................. 1
PACKAGE CONTENTS .......................................................................................................... 1
SPECIFICATIONS .................................................................................................................. 2
HADWARE INSTALLATION ................................................................................................... 3
CONNECTION DIAGRAM ...................................................................................................... 3
DVI OVER SINGLE CAT5 SERIES LINEUP ..................................................................... 4
NOTICE ................................................................................................................................... 5
WARRANTY ............................................................................................................................ 6
has been tested for conformance to
