GoMax Electronics EX-27 Series User Manual

Usb 2.0 extender over single cat.x

Advertisement

E
X
E
X
USB 2.0 Extender over Single Cat.X
User Manual
TX
-
2
7
-
2
7
RX
rev: 181129
Made in Taiwan
Safety and Notice
The EX-27
USB 2.0 Extender over Single Cat.X
regulations and requirements, and has been certified for international use. However, like all
electronic equipments, the EX-27 should be used with care. Please read and follow the safety
instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
Introduction ................................................................................................................ 1
Features ........................................................................................................................ 1
Package Contents ................................................................................................... 1
Specifications .............................................................................................................. 2
Panel Description ...................................................................................................... 3
Transmitting unit ► EX-27-TX ................................................................................. 3
Receiving unit ► EX-27-RX .................................................................................... 4
Connection Diagram .................................................................................................. 5
Limited Warranty ........................................................................................................ 6
has been tested for conformance to safety

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX-27 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for GoMax Electronics EX-27 Series

  • Page 1 Safety and Notice The EX-27 USB 2.0 Extender over Single Cat.X has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the EX-27 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
  • Page 2 INTRODUCTION SPECIFICATIONS The EX-27 USB 2.0 Extender over Single Cat.X makes USB equipped device accessible over Model Name EX-27 single Cat.X cable. EX-27 helps you extend USB peripheral device up to 264feet (80 meters) over single Technical EX-27-TX EX-27-RX Cat.X cable. The extender consists of two units, local and remote unit. The local unit connects to the PC and the remote unit connects to the peripheral device, such as USB printers, USB camera, USB Storage Role of usage Transmitter [TX]...
  • Page 3 PANEL DESCRIPTION ► Transmitting unit EX-27-TX Receiving unit ► EX-27-RX Front Panel Rear Panel Front Panel Rear Panel USB: Connect to USB Host USB: Connect to USB Device 2-Pin Dip Switch for Equalization Selection: USB: Connect to USB Device Use the dip switch(please refer to below table) to adjust equalization level. The equalization level 2-Pin Dip Switch for Equalization Selection varies from EQ#1 (MAX or strongest) to EQ#3 (MIN or weakest) for respective transmission length Use the dip switch(please refer to below table) to adjust equalization level.
  • Page 4 LIMITED WARRANTY CONNECTION DIAGRAM EX-27 USB 2.0 Extender over Single Cat.X The SELLER warrants the to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.

This manual is also suitable for:

Ex-27-txEx-27-rx
