- Page 1 & & HDMI Extender & Splitter over IP User Manual To avoid EMI issue, complete STP Cat6 cable is strongly recommended! rev: 120403 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the CV-57I-TX & RX and SP-5022I should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
TMDS to distant display monitors including HDMI or DVI enabled TV sets or LCD PC monitors. Besides CV-57I-TX & RX also supports HDCP and this flexibility makes HDCP compliant DVD players or PS3 transmit utmost high quality video and audio with a greater distance at the minimal cost, when integrating several components apart. -
Page 4: Specifications
SPECIFICATIONS Model Name CV-57I SP-5022I Technical CV-57I[Tx] CV-57I[Rx] 1x2 Distribution Role of usage Transmitter [TX] Receiver [RX] Amplifier Transciver HDMI compliance HDMI 1.3 HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 HDMI over UTP Full HD (1080p)-100m (330ft) [CAT.X] transmission [24-bit]... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS ► Transmitting unit CV-57I-TX Front Panel Rear Panel HDMI IN: Connects to a HDMI source with a HDMI male-male cable Power LED Indicator: Power LED indicator Signal LED Indicator: Signal LED indicator +5V DC: Connect to 5V DC power supply HDMI Signal OUT: RJ-45 Network connector Receiving unit ►... -
Page 6: Package Contents
+5V DC: Connect to 5V DC power supply HDMI Signal OUT 1-2: RJ-45 Network connector HDMI Signal IN: RJ-45 Network connector PACKAGE CONTENTS CV-57I-TX ● 1x CV-57I-TX ● 1x DC 5V 2A wall wart ● 1x User Manual CV-57I-RX ● 1x CV-57I-RX ●... -
Page 7: Connection Diagram
CONNECTION DIAGRAM 1 to 1 Cascading... -
Page 8: Notice
NOTICE 1. When adjusting the signal level on the receiver unit, please dial the rotary control switch from MIN to MAX and stop turning the rotary switch whenever the audio/video is playing normally. Inappropriate signal level setting may cause overpowering issue that would shorten the product life significantly! 2. -
Page 9: Warranty
Also, the technical information contained herein regarding the CV-57I-TX & RX and SP-5022I features and specifications is subject to change without further notice.
