Key Features

Hybrid
Various video format of 1080P, 720P, 960H, NTSC/PAL, EX-SDI
(DoubleReach) and IP cameras can be displayed simultaneously.
It supports real-time live monitoring and record/playback on
various format and it records from 5 seconds before event and
record up to 30fps per channel.
 Various video record
- HD 1080p camera
- HD 720P camera
- EX-SDI (Double Reach) camera
- SD 960H camera
- SD (NTSC/PAL) camera
 Supports manual & schedule recording at all times.
 Supports archiving event list(sensor, video loss, motion detection, Text, Fire detection)
 Max 5 seconds pre-alarm recording per each channel
FULL HD
FULL HD high quality video shows far superior resolution than SD video product. Over 1200 TV lines at 1080p
resolution can be visible.
Full HD
SD
HD-SDI
It is product using HD-SDI technology transmitting HD quality images through coaxial cable.
Supporting resolution is as follows
Transmission method – SMPTE 292M : HD-SDI

Resolution – 1920x1080p 25/30Hz, 1280x720p 50/60Hz

EX-SDI (Enhances transmission distance by Max. 400m)
It is a technology that increases transmission distance by 400m for HD-SDI cameras.
If DR101P-TX (EX-SDI transmitter) is connected with HD-SDI camera, or if D1080 series camera is connected
directly to Penta-Brid DVR, HD video's transmission distance can be extended up to 400m.
5
1080P Resolution
720P Resolution
D1 Resolution
SD : D1
HD : 720p
Full HD : 1080p
