Digi TransPort ® WR44v2 Installation Guide

Digi TransPort WR44v2 Specifications

Specifications
General Features:
Dimensions 5.7" x 8.3" x 1.6"
(L x W x H) (145 mm x 210 mm x 40 mm)
DSL Variant 5.7" x 10.3" x 1.6"
(145mm x 262mm x 40mm)
Weight 1.98 lb (0.9Kg)
DSL Variant 2.5lb (1.4Kg)
Other Standard dual SIM (SIM protection cover option); Conformal coating (option)
RF Features:
GSM Models
GPRS GPRS Class 10, Quadband 850/900/1800/1900 MHz
EDGE GPRS Class 10/EDGE Class 10, Quadband 850/900/1800/1900 MHz
HSDPA/HSUPA/UMTS 850/900/1900/2100 MHz with Rx Diversity
CDMA Models
CDMA/EV-DO Rev A Dualband 800/1900 MHz with Rx Diversity; Optional multi-mode GSM/EV-DO
Gobi support; 450 MHz, 3.1 Mbps down / 1.8 Mbps up, R-UIM support
Power Requirements:
Power Input 9-36VDC
Power Supply 100 - 240 VAC 50/60 Hz with barrel connector, Optional Molex connector
with bare wire leads
Power Consumption 8 W @ 12 VDC
Environmental:
Operating WR44: 0° C to +60° C
Temperature
WR44 Extended Temp/WR44R:
-40° C to +75° C; -20° C to +75° C (Wi-Fi models only)
Reduced cellular performance may occur above +60° C.
Note: Products that ship with standard temperature power supplies (part
numbers ending in –SU or –SW) are limited to 0-40C which is the operating
temperature range of the power supply.
Relative Humidity 20% to 95% (non-condensing)
Ethernet Isolation 1.5 kV
Serial Port Protection (ESD) 1.5 kV
Approvals:
Mobile Certifications - GSM/ PTCRB, NAPRD.03, GCF-CC, R&TTE, EN 301 511
UMTS
Mobile Certifications - CDMA/ CDG TIA/EIA-690, CDG TIA/EIA-98-E
EV-DO
Wireless Carrier Certifications Certified by most major carriers. See
Safety UL 60950, CSA 22.2 No. 60950, EN60950
Emissions / Immunity CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55022 Class A
Digi TransPort WR44 / WR44 R
www.digi.com for current listing.
Page 22
Digi TransPort ® WR44v2 Installation Guide

Digi TransPort WR44v2 Accessories

AC Power Supplies
North America (NA) 76000823
International (Intl.) 76000823
NA - Extended Temp. 76000790
Intl. - Extended Temp. 76000789
DC Power Cords
Barrel Plug to Bare Wire 76000807
Barrel Plug to 12V Auto Power Outlet 76000810
4-pin to 12V Auto Power Outlet 76000809
4-pin to Bare Wire 76000808
Mounting Brackets
DIN Rail 76000777
Wallmount 76000778
Rackmount 76000840
Adapters
RJ45 to DB9 Female - 6' 76000855
RJ45 to DB25 Male - 6' 76000856
RJ45 to DB25 Female - 6' 76000857
Cables
RJ45 to RJ45 - 0.5m 76000825
RJ45 to RJ45 - 2m 76000826
RJ45 to RJ45 Crossover - 2m 76000827
RJ45 to RJ45 - 12' 76000828
RJ45 to RJ45 Crossover - 12' 76000829
SMA Male to SMA Female - 5m 76000830
SMA Male to SMA Female - 10m 76000831
SMA Male to SMA Female - 15m 76000832
DB9 Female to DB9 Male - 6' 76000858
SIM Slot Cover Plates
10-pack 76000785
10-pack Starter Kit 76000779
Torx Driver Tool 76000853
