Rev 1. 02-02-2021
Wide Band EMC Benchtop Power Amplifier
18GHz ~40GHz
= +25⁰C
A
Parameter
Frequency Range
Gain
Gain Flatness
(0℃~+50℃ )
Input VSWR
(CW)
Isolation S12
Efficiency at Psat
Weight
Impedance
Finish
Features
• Wideband Power Amplifier
•
Gain:
50dB
• Output Power +44.5dBm typical
• Supply Voltage: 110V/220V AC
Typical Applications
• Wireless Infrastructure
• Military & Aerospace
• Test and Measurement
Min.
Typ.
18
48
50
±5
±3
2
42
44.5
60
2
10
360
50
2.92mm-Female
White Painted Finish
Sales: sales@rflambda.com
REMC18G40GC
Max.
Units
40
GHz
dB
dB
dB
:1
dBm
dBm
dB
A
%
ounces
Ohms
RF-LAMBDA USA
www.rflambda.com
Technical : support@rflambda.com
