- Page 1 KEYHOLE SAW...
-
Page 2: Security Instructions
Security instructions Caution Read all safety warnings and all instructions. Failure to follow all warnings and instructions can result in electric shock, fire, and / or serious injury. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 3 4) Use and care of power tools a. Do not force the tool. Use the right power tool for each use. b. Do not use the power tool if its ignition switch does not work. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
-
Page 4: Additional Safety Instructions
Additional safety instructions Safety instructions for saws Court procedures Attention Keep your hands away from the cutting area and the blade. Keep your second hand on the auxiliary handle or motor housing. If both hands are holding the tool, the blade cannot cut them. -
Page 5: Other Risks
b. Check the operation of the lower protection spring. If the guard and spring are not working properly, they must be serviced before use. Bottom guard may be slow due to damaged parts, gummy deposits, or accumulation of debris. c. The lower guard can be manually retracted only for special cuts such as "plunge cuts"... -
Page 6: Product Description
Product description 1. Mango 2. On / Off switch 3. On / Off switch lock button 4. Locking lever for cutting depth adjustment. 5. Cable 6. Disc protector 7. Set screw 8. Disc / saw blade 9. Parallel stop and guide bar 10. - Page 7 Always respect the safety regulations and use the appropriate PPE for this type • of task, such as protective glasses or gloves, among others. • Do not use defective saw blades / discs or those with cracks and defects. Do not use flanges or flange nuts with a hole that is larger or smaller than that of •...
- Page 8 Adjusting the depth of cut • Release the blade guard or lock lever (4). Flip down the cover. • Adjust the depth of cut using the scale. The teeth of the saw or disc should • protrude approx. 2mm from wood Push the blade guard or lock lever down.
-
Page 9: Maintenance And Troubleshooting
Start up Before pressing the On / Off switch, check that the blade is properly installed, that the moving parts are free of problems, and that the retaining screws are tight. On and off To turn on: Press the lock button and the switch at •... -
Page 10: Exploded View
Exploded view... - Page 11 KEYHOLE SAW...
